MAC090A-0-ZD-4-C/110-A-0/WI521LV
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911258321
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
MAC Permanent Magnet Motor manufactured by Bosch Rexroth Indramat. This motor has a power connecter on Side A. This motor also includes a Incremental Encoder with Standard Mounting encoder and a Not Equipped blocking brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth Indramat is a manufacturing company that designs and produces equipment integral to the operation and control of industrial machinery. The MAC090A-0-ZD-4-C/110-A-0/WI521LV is a servo motor from its MAC AC line of servo drives. It can be utilized in several applications including workspace handling facilities and robotics. The unit is a brushless motor that makes use of electronic commutation, which involves using semiconductor switches to switch the stator windings of the motor off and on periodically. The motor is also constructed with permanent magnets and features both a tachofeedback, which is customary for motors in the MAC AC series, as well as a standard mounted encoder which can be incremental or absolute.
The unit does not offer options for surface cooling with an axial or radial blower. Instead, it employs natural convection for heat dissipation and cooling. The unit has a nominal motor speed of 2000 revolutions per minute. Its power connection is to the A side of the unit. The motor does not feature either a standard bl ?Cking brake or a heavy-duty blocking brake. Its centering diameter is 110 mm and the motor size is 090.
The device has a maximum peak of pulse current value of 53 amperes. Its continuous current at standstill is 8.1 A while its continuous torque at standstill is 3.7 Nm. The mass of the unit is 12.5 kg and its thermal time constant, which is a measure of how long it takes for the unit?s thermistor to respond to changes in ambient temperature, is 45 minutes. The windings inductance and windings resistance at 20 ?C values are 1.9 mH and 1.85 Ohm, respectively. The product is delivered with a 12-month warranty from Wake Industrial when you order from our site.
