MAC063A-0-RS-4-C/095-A-0/WI634BX/S001
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911226098
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
MAC Permanent Magnet Motor manufactured by Bosch Rexroth Indramat. This motor has a power connecter on Side A. This motor also includes a Incremental Encoder with Standard Mounting encoder and a Not Equipped blocking brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth's MAC motors are high-performing servo motors that work seamlessly with TDM, KDS, and DSC drive controllers to create quick-acting drives. They possess electronic commutation and can utilize peak torque at a wide range of speeds. These motors suit various equipment such as robotics, textile machines, machine tools, and handling equipment.
The MAC063A-0-RS-4-C/095-A-0/WI634BX/S001 is a model of AC servo motor from the MAC series by Bosch Rexroth designed to support the direct attachment of pinions and belt pulleys to the shaft due to its strong bearing assembly's capability of handling high radial loads. Also, this motor's housing, power cables, tachofeedback cables, and encoder cables are all sealed against dust and water ingress and conform to the IP 65 standard as per DIN 40 050. The MAC063A-0-RS-4-C/095-A-0/WI634BX/S001 AC servo motor is equipped with natural convection as its cooling method, which allows the heat generated during operation to be dissipated into the surrounding air. Additionally, this motor has a nominal speed of 6,000 revolutions per minute, making it suitable for high-speed applications.
Its rotor is designed with unique materials and permanent magnets that provide low inertia. This, combined with its favorable torque-inertia ratio, allows it to perform at high dynamics. The motor also features tachofeedback and a mounted encoder that detects and evaluates rotor position and velocity. Its rotor moment of inertia is 2.4 x 10-4 kgm2, further improving its high-performance capabilities. In addition, the brushless design and lifetime-lubricated bearings of the MAC063A-0-RS-4-C/095-A-0/WI634BX/S001 eliminate the need for maintenance, resulting in high operational reliability. This motor is equipped with thermo switches integrated into its windings and stator housing to prevent damage from overloads.
