MPN: 608750101
The Bosch Rexroth Indramat LTE 45 0 608 750 101 is a servo amplifier from the LTE Servo Amplifiers series with a peak output current of 45 Amps and a rated output current of 10 Amps. Its nominal power at 230 V is 2000 VA, with a peak power of 7200 VA, and it operates at a supply frequency of 50/60 Hz. The unit measures 298 mm deep, 266 mm high, and 125 mm wide, and its protection type is IP40 with a weight of 11 kg.
Internal Product Review
The LTE 45 0 608 750 101 is a Bosch Rexroth Indramat servo amplifier that delivers 10 A rated output current and 45 A peak output current. IP40 protection and Protective Earth construction support dependable cabinet integration in demanding automation service. A 7200 VA peak power rating makes this unit a strong choice for dynamic servo applications.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The LTE 45 0 608 750 101 is a servo amplifier from the LTE Servo Amplifiers series manufactured by Bosch Rexroth Indramat. The unit conditions line power and delivers controlled DC energy to matched servo motors, allowing precise velocity and torque regulation in automated machining centers, material-handling axes, and assembly stations. By integrating current control, overcurrent protection, and monitoring functions inside a compact enclosure, the amplifier simplifies cabinet wiring in multi-axis drive packages. It also supervises operating conditions so the connected axis can respond consistently during starts, stops, and changing load conditions.
Under a 230 V supply, the amplifier can sustain a nominal apparent power of 2000 VA, while its internal converter produces a regulated bus voltage of 310 VDC for the motor windings. Continuous motion demands are handled with a rated output of 10 A, and the design supports a momentary surge of 45 A so rapid accelerations or load peaks do not stall the axis. Line protection is provided by a 16 A time-lag fuse that tolerates short inrush events without nuisance trips. Compatibility with industrial mains is maintained through a 50/60 Hz input frequency, and a protective-earth connection with three-sided ventilation slots helps direct fault current safely to ground while supporting heat dissipation inside the enclosure.
The amplifier’s energy headroom extends to a peak apparent output of 7200 VA, giving additional margin during short acceleration bursts. An enclosure rating of IP40 allows installation inside standard switchgear cabinets where falling particles may be present, and a shipped mass of 11 kg keeps the unit manageable during panel assembly. Its 125 mm width, 266 mm height, and 298 mm depth suit narrow column arrangements, while operation is supported up to 2000 m elevation. Typical input power consumption of 1800 VA helps keep upstream transformer demand within common plant service limits.
