HVE03.2-W030N/S200 Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911190224
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat HVE03.2-W030N/S200 is a power supply unit in the HVE Power Supply Units series, offering a rated power of 30 kW and a control voltage output of 300 W. It features internal air cooling with a built-in blower, a mains current of 46 A, and has a bleeder peak power of 100 kW. The unit has a height of 498 mm, a depth of 308 mm, and weighs 16 kg.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HVE03.2-W030N/S200 power supply unit is produced by Bosch Rexroth Indramat as part of the HVE Power Supply Units series. It connects three-phase mains lines to a shared DC bus for multiple servo drives, combining rectification, energy return, and braking control in one module. In automation cabinets, this unit stabilizes the bus voltage and eliminates the need for a separate braking resistor on each axis during coordinated motion. It is used where several axes accelerate and decelerate on a common power section in packaging, printing, and material-handling equipment.
The supply can deliver a continuous output of 30 kW, which is the steady power available to the drives during normal operation. Short-term overloads are handled through a DC bus capability of 60 kW, allowing brief current surges without tripping. Regenerative braking energy is managed by an internal bleeder rated for 1.5 kW continuously, while a peak rating of 100 kW lets it absorb sudden energy spikes when several axes stop at the same time. This braking path helps keep DC bus voltage under control during rapid deceleration. Core conversion losses are limited to 175 W, which reduces enclosure heat, and internal air circulation with a built-in blower moves this heat through the IP10 housing so no external fan kit is required.
The DC link stores charge in a bus capacitor of 1.4 mF, supplying immediate current to inverters between mains cycles and smoothing voltage ripple. Auxiliary electronics such as control logic and contactors draw from a separate output that provides 300 W of control power. From power up, the unit charges the bus to operating level in 1.6 s, which helps reduce start-up delay, and during full load the mains side draws 46 A for cable sizing and protective device selection. Stored energy in the DC link also supports stable inverter operation during rapid load changes. The housing measures 498 mm × 150 mm × 308 mm and has a mass of 16 kg, so it fits standard 300 mm deep cabinets while keeping panel weight moderate.
Frequently Asked Questions about HVE03.2-W030N/S200:
Q: What is the rated power capacity of the HVE03.2-W030N/S200 unit?
A: The HVE03.2-W030N/S200 power supply unit has a rated power output of 30 kW.
Q: What cooling method does the HVE03.2-W030N/S200 utilize?
A: This model uses internal air cooling with a built-in blower for temperature management.
Q: What is the maximum bleeder peak power of the HVE03.2-W030N/S200?
A: The peak power that can be handled by the bleeder resistor in this unit is 100 kW.
Q: What is the mains current consumption for the HVE03.2-W030N/S200 power supply?
A: The mains current requirement for the HVE03.2-W030N/S200 is 46 A.
Q: What is the internal DC bus capacity of the HVE03.2-W030N/S200 power supply unit?
A: This unit features an internal DC bus capacity of 1.4 mF for energy storage and distribution.
