HMS01.1N-W0020-A-07-NNNN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911295323
The HMS01.1N-W0020-A-07-NNNN Drive Controller is manufactured by Rexroth Indramat Bosch. This drive controller is Not Equipped with a power supply and has an Internal Air Blower cooling mode. The maximum current of this drive controller is 20 and the nominal current is DC 700 V.

HMS01.1N-W0020-A-07-NNNN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911295323
The HMS01.1N-W0020-A-07-NNNN Drive Controller is manufactured by Rexroth Indramat Bosch. This drive controller is Not Equipped with a power supply and has an Internal Air Blower cooling mode. The maximum current of this drive controller is 20 and the nominal current is DC 700 V.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a HMS01.1N-W0020-A-07-NNNN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The HMS01.1N-W0020-A-07-NNNN is a power section by Bosch Rexroth. This device is a part of a drive controller and has a line code of 1 and a design code of 1. The unit features three terminals A1, A2 and A3 for power connection at the connected motor. The controller encompassing the product must not be used if it has damaged components or shows signs of malfunctioning. The power section has a maximum current rating of 20A. The unit comes with X5 and X6 connectors as well as a touch guard. The device is fitted with a type plate that gives various details of the section.

The power section has a nominal DC bus voltage rating of 700VDC. It is not equipped with any power supply. The product is cooled during operation using internal air circulation through an integrated blower. The device is CSA Certified and UL Listed. The unit makes use of a Class 1 copper field wiring material. It must not be used in low voltage network supplying public residential areas to avoid the possibility of high interference. The drive controller can operate with an asynchronous, synchronous kit spindle, synchronous torque and synchronous linear motors.

The connections to and from the power section should be done using only IndraDyn and IndraDrive connection cables. The unit has a rated input control voltage rating of 24V +/-20%. It operates at a maximum ambient temperature of 40°C with rated data and 55°C with derated data. The device has an output frequency range of 0 to 1,000Hz. The X5 connector is used for connecting the motor. The connection cable has a minimum cross-sectional area of 1mm2 and a maximum cross-sectional area of 4mm2. The grounding terminal is used for connecting the equipment grounding conductor of the motor. The drive controller can be shipped worldwide with a one-year Wake Industrial warranty.

HMS01.1N-W0020-A-07-NNNN Documents

  • HMS011NW0020A07NNNN
  • hms01.1n-w0020-a-07-nnnn
  • HMS01 1N W0020 A 07 NNNN

HMS01.1N-W0020-A-07-NNNN Technical Specifications

Cooling Mode: Internal Air Blower
Maximum Current (A): 20
Nominal Current: DC 700 V
Power Supply: Not Equipped
