HDS02.1-W040N-HS76-01-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911271933
The HDS02.1-W040N-HS76-01-FW Servo Controller is manufactured by Rexroth Indramat Bosch. This controller is cooled by an Internal Blower, and has a rated current of 40A. This HDS controller has a Sercos Command Communication, and the Controller Family is DIAX04.

HDS02.1-W040N-HS76-01-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911271933
The HDS02.1-W040N-HS76-01-FW Servo Controller is manufactured by Rexroth Indramat Bosch. This controller is cooled by an Internal Blower, and has a rated current of 40A. This HDS controller has a Sercos Command Communication, and the Controller Family is DIAX04.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a HDS02.1-W040N-HS76-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Rexroth Indramat is a global brand known for reliable, innovative and long-lasting products in the automation sector. They specialize in making assembly technology, industrial hydraulics, mobile hydraulics, servo drives, and servo motors. One of their most successful products is the HDS series of their 2nd generation drive controllers.

The HDS series of drive controllers are characterized as reliable and flexible products. The HDS02.1-W040N-HS76-01-FW is part of the HDS series by Rexroth Indramat. It is a 2-line, version 1 drive controller. It has air, internal (with built-in blower) cooling system. Their efficient cooling system ensures that the unit is kept well ventilated. The HDS02.1-W040N-HS76-01-FW has a current rating of 40 A. This controller belongs to the DIAX04 controller family and has a SERCOS interface. The drive controllers with the SERCOS interface are connected by optic fibers to the associated control. Therefore, the optic fiber must be ordered separately by the user.

The modular concept of the DIAX04 allows for a flexible combination of different AC drives to create compact drive packages. The HDS02.1-W040N-HS76-01-FW drive controller is intended to be connected to an HVR or HVE supply unit. These supply units provide all the power and signals needed to run the drive controller properly. The function ID code for this controller is 76 with the 1st version of function ID. HDS02.1-W040N-HS76-01-FW firmware must be ordered as a separate subitem. The operating temperature for HDS02.1-W040N-HS76-01-FW is between 5˚C to 45˚C with an installation elevation between 0 to 1000 m above sea level. The weight of HDS02.1-W040N-HS76-01-FW is 8 kg. This drive controller must be stored in a dry, dust and shock-free location and transported only with suitable transportation equipment and proper packaging. The HDS02.1-W040N-HS76-01-FW can be shipped to any address worldwide with a one-year warranty period from Wake Industrial.

HDS02.1-W040N-HS76-01-FW Documents

  • HDS021W040NHS7601FW
  • HDS02 1 W040N HS76 01 FW
  • hds02.1-w040n-hs76-01-fw

HDS02.1-W040N-HS76-01-FW Technical Specifications

Command Communication: Sercos
Controller Family: DIAX04
Cooling: Internal Blower
Rated Current: 40A
