Product Description:

The HDS04.2-W200N-HS76-01-FW is a drive controller built by Bosch Rexroth Indramat. Designed as a rack-mounted module, it converts digital motion commands into regulated power for servo axes used in assembly cells, material-handling gantries, and similar equipment. The controller links the automation system to the attached power stage so motors receive the current shaping and control signals required for accurate speed and position control. In automated equipment, it supports repeatable motion by translating network commands into motor-side regulation during frequent starts, stops, and direction changes.

Communication with the control system is handled through SERCOS fiber optics, allowing cyclic exchange of setpoint, feedback, and diagnostic data. The unit is part of the DIAX04 controller family, so it follows the platform layout used by other compatible axis modules. A continuous output current of 200 A gives the amplifier the capacity needed for rapid acceleration of large servomotors and sustained operation under high load. Thermal management relies on a built-in internal air blower, which moves cabinet air across the heat sinks instead of requiring an external cooling plate. Because data is exchanged in real time, the higher-level controller can monitor drive status and respond quickly to changing load conditions. The product is part of Line 04 in the series.

The drive is identified as Version 2. It belongs to the HDS Drive Controllers series, which uses a common mechanical format for rack-based motion systems. This arrangement allows the module to fit with compatible power supplies and backplanes while keeping control and power regulation functions in the same housing. The unit is intended for high-current axis applications that need stable thermal performance and consistent communication behavior across a multi-axis cabinet.
