HDS04.1-W200N-HS09-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911281501
The Bosch Rexroth Indramat HDS04.1-W200N-HS09-01-FW is an HDS Drive Controller from the HDS Drive Controllers series. It features a rated current of 200 Amps and relies on a built-in internal air blower for cooling. This controller utilizes a SERCOS command communication interface and is part of the DIAX04 controller family.
Internal Product Review
The HDS04.1-W200N-HS09-01-FW is a Bosch Rexroth Indramat HDS drive controller with SERCOS communication and a 200 A rated current. Built-in internal air blower cooling supports stable thermal performance in DIAX04 motion platforms. A strong choice for high-demand servo applications requiring precise networked control.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HDS04.1-W200N-HS09-01-FW is a modular drive controller produced by Bosch Rexroth Indramat for multi-axis automation racks. It coordinates servo and spindle axes in assembly machines, packaging lines, and metal-cutting tools that require regulated motion across several connected drive modules. The unit plugs into a common bus module, processes motion commands, and issues pulse-width-modulated gate signals to attached power sections. By supporting closed-loop current, velocity, and position regulation, it links machine mechanics with higher-level numerical or PLC supervision inside industrial motion systems. This role allows the controller to support responsive axis behavior during acceleration, speed control, and positioning tasks.
The controller has a rated output of 200 A, allowing it to energize large servo axes without external boosters. Command and diagnostic data travel over SERCOS, so a fiber-optic ring ties the HDS rack to the master control while maintaining deterministic cycle times. Thermal regulation depends on a built-in air blower, which directs cabinet air across the heat sink to limit semiconductor temperatures during continuous operation. The device belongs to the DIAX04 family and is part of Line 04, which gives it mounting dimensions that match other modules in the same design line. The product type is listed as an HDS Drive Controller, separating it from supply cards and I/O cards in the same rack.
The unit is Version 1. It shares the backplane power bus and diagnostic LEDs with companion cards in the rack. The module also uses the same loop topology as related controllers, so it fits into a common axis control stack without extra adapters. Shared electrical and status connections help the rack remain organized when several coordinated axes are installed side by side.
