The Bosch Rexroth Indramat HDS04.1-W200N is a drive controller from the HDS Drive Controllers series. It uses a built-in internal air blower for cooling and is rated for 200 Amps of current. The controller has a protection category of IP10 and is insulated to class C as per DIN VDE 0110.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth Indramat manufactures the HDS04.1-W200N within the HDS Drive Controllers series. The unit is designed to command and protect servo axes by supplying controlled DC link energy, monitoring feedback, and issuing fault responses when operating conditions move outside acceptable limits. It serves as the control stage inside modular drive racks, enabling synchronized positioning and stable speed control in printing presses, robotic handlers, and other general automation lines. Because it combines power regulation with protective monitoring, it supports coordinated axis behavior during both acceleration and steady-state operation.
The controller supplies a continuous output of 200 A, allowing it to support high-torque motor modules during demanding motion cycles without saturating the current loop. Thermal loads produced at this operating level are managed by a built-in air blower, so heat is removed from the power section without requiring separate external cooling hardware. The housing has an IP10 rating, which helps prevent accidental contact with live internal parts while still requiring installation inside a closed rack or cabinet. The controller operates in ambient temperatures from +5 to +45 °C and at mounting heights up to 1000 m above sea level; above that height, current and switching frequency must be reduced. This arrangement suits centralized rack systems where airflow is guided through adjacent modules.
For applications with elevated cabinet temperatures, the drive can still operate when ambient peaks reach +55 °C, provided output and switching limits are reduced proportionally. During logistics or maintenance periods, it can be stored from -30 to +85 °C without damage to the electrolytic capacitors or control logic. The power circuitry uses Class C insulation according to DIN VDE 0110, which allows higher permissible temperatures than conventional F-class devices. This insulation system supports the electrical clearances used in the power section under normal industrial duty. The unit is part of Line 04 and is Version 1.
Frequently Asked Questions about HDS04.1-W200N:
Q: What cooling method does the HDS04.1-W200N drive controller use?
A: The HDS04.1-W200N controller utilizes a built-in internal air blower for cooling, ensuring adequate temperature control during operation.
Q: What is the rated current for the HDS04.1-W200N drive controller?
A: This model has a rated current capacity of 200 A, supporting applications requiring high current demand.
Q: What insulation classification does the HDS04.1-W200N drive controller have?
A: The HDS04.1-W200N is classified as insulation class C according to DIN VDE 0110.
Q: What is the ambient temperature operating range of the HDS04.1-W200N?
A: The permissible ambient temperature range for operation is between +5°C and +45°C.
Q: What is the maximum installation elevation for the HDS04.1-W200N?
A: The HDS04.1-W200N is designed for installation up to 1000 meters above sea level.
