The Bosch Rexroth Indramat HDS03.1-W100N-HS80-01-FW is part of the HDS Drive Controllers series and belongs to the DIAX04 controller family. This drive controller features a SERCOS communication interface and a built-in internal air blower cooling method. It is rated for 100 Amps of current.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HDS03.1-W100N-HS80-01-FW from Bosch Rexroth Indramat belongs to the HDS Drive Controllers series and serves as the axis-controller module inside DIAX motion racks. It supervises torque, speed, and position loops for connected servo axes while forwarding diagnostic and status data to a higher-level PLC, which supports coordinated motion in packaging, material handling, and machining equipment. In a rack-based drive system, it acts as the regulation stage that helps connected motors follow commanded motion profiles during acceleration, deceleration, and steady-speed operation. By combining control logic, power electronics, and communication hardware in one enclosure, the unit reduces panel wiring and supports compact cabinet layouts in automated production lines.
The command channel relies on the SERCOS interface, a deterministic fiber-optic ring that carries cyclic setpoints and feedback between each drive and the master without galvanic coupling. A continuous output capability of 100 A is the maximum motor current the controller can regulate under rated ambient conditions, so the connected axis must be matched to that limit. The controller is part of the DIAX04 family, which keeps its diagnostics and parameter structure consistent with other modules in the same platform. Thermal management is handled by a built-in air blower that pulls cooling air through the heat sink to maintain operating temperature without external ducting.
The unit is Version 1 and belongs to Line 03. Its mechanical dimensions and connector positions match other third-line modules in the same rack, which supports orderly installation in multi-axis assemblies. Within system documentation, the product is identified as an HDS Drive Controller. It does not include a built-in power supply or brake resistor, so those functions are provided by separate system modules. This arrangement separates axis control from shared power functions in larger drive systems and allows the rack to be configured around the requirements of the connected axes.
Frequently Asked Questions about HDS03.1-W100N-HS80-01-FW:
Q: What type of command communication interface does the HDS03.1-W100N-HS80-01-FW use?
A: The HDS03.1-W100N-HS80-01-FW features a SERCOS command communication interface for digital motion control tasks.
Q: Which controller family is the HDS03.1-W100N-HS80-01-FW part of?
A: This drive controller belongs to the DIAX04 controller family, which is known for its modular and versatile drive systems.
Q: How is the HDS03.1-W100N-HS80-01-FW drive controller cooled?
A: A built-in internal air blower cools the HDS03.1-W100N-HS80-01-FW during operation.
Q: What is the rated current of the HDS03.1-W100N-HS80-01-FW drive controller?
A: The HDS03.1-W100N-HS80-01-FW provides a rated current output of 100 A for industrial drive applications.
Q: What version is the HDS03.1-W100N-HS80-01-FW model?
A: This drive controller is categorized under version 1 as specified by the manufacturer.
