HDS03.1-W100N-HS76-01-FW
MPN: R911282053
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 3-5 Days
The HDS03.1-W100N-HS76-01-FW is a drive controller manufactured by Bosch Rexroth Indramat. As part of the HDS Drive Controllers series, it features a power rating of 100 amperes and operates on a line voltage of 3-phase, 230–480 V AC. The controller weighs approximately 15 kg and employs internal cooling with built-in fans.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Rexroth’s HDS series drive HDS03.1-W100N - HS76 - 01 -FW is constructed for motor control on industrial level. It provides a rated current of 100.0 A for sturdy operations and it can handle 35.0 A of continuous current with 8 kHz, while it offers 50.0 A current at 4 kHz of switching frequency.
The HDS03.1-W100N - HS76 - 01 -FW drive consumes 20.0 W of energy during signal processing of 24 V and its power loss rating is 280 W. Its built-in blower helps in maintaining operatable ambient temperature and its insulation ratings meets the DIN VDE 0110 standard of class C. The drive’s protection category is defined as IP10 and its installation is recommended up to 3300 ft of altitude without derating. The HDS drive supports the SERCOS communication interface and it ensures reliable command communication via the SERCOS protocol. Its software module HSM is included for storing parameters and firmware, while its firmware comes separate on costumer’s order and specified parameters, as this unit is designed for modular expansion based on operational requirements. The controller is adaptable with plugin modules for expanded functionality and its RS232 interface provides transmission rates of 9600/19200 baud. The HDS drive comes with a manual fault reset button with red color and provides dedicated grounding points for motor safety.
The HDS03.1-W100N - HS76 - 01 -FW drive is compatible with HVE and HVR power supply modules. Its electrostatic precautions are essential during storage and handling. Its supports up to 75 m of wired length from the system and its RS232 provides transmission over a length of up to 15 meters. The HDS drive has AS+ and AS- designated control relay points for DC 20 to 30 V, with power capacity of 1.5 W.
Frequently Asked Questions about HDS03.1-W100N-HS76-01-FW:
Q: What is the purpose of the HDS03.1-W100N-HS76-01-FW drive’s built-in blower?
A: The built-in blower maintains the drive’s operational temperature, ensuring consistent performance in demanding environments. This feature is crucial for preventing overheating during continuous operations.
Q: How does the HDS03.1-W100N-HS76-01-FW support modular expansion?
A: The HDS03.1-W100N-HS76-01-FW is designed with adaptability in mind. Its plugin modules allow for easy expansion of functionality according to changing operational requirements.
Q: Why does the HDS03.1-W100N-HS76-01-FW drive support the SERCOS protocol?
A: The SERCOS protocol enables real-time communication for precise control of industrial machinery. This is particularly beneficial in applications requiring high-speed and synchronized operations.
Q: What is the significance of the HDS03.1-W100N-HS76-01-FW’s insulation rating of Class C?
A: The Class C insulation rating meets the DIN VDE 0110 standard and ensures reliable operation in higher temperature environments, extending the drive's lifespan and safety.
Q: How does the RS232 interface of the HDS03.1-W100N-HS76-01-FW support long-distance communication?
A: The RS232 interface allows for transmission over distances of up to 15 meters, ensuring reliable communication over extended systems with minimal signal loss.
