HDS03.1-W075N-HS33-01-FW
Wake Industrial LLC is not an authorized distributor of this product.
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships Today
The Bosch Rexroth Indramat HDS03.1-W075N-HS33-01-FW is an HDS Drive Controller from the HDS Drive Controllers series and operates with a rated current of 75 Amps. It features SERCOS command communication and uses a built-in internal air blower for cooling.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HDS03.1-W075N-HS33-01-FW is a drive controller produced by Bosch Rexroth Indramat within the HDS Drive Controllers series. As a closed-loop power module, it regulates three-phase servo or main-spindle motors in automated machining cells, transfer lines, and assembly stations. The controller belongs to the DIAX multi-axis platform, letting several axes share a common DC bus for compact cabinet layouts. Its task in industrial automation is to translate digital setpoints from the machine control into accurate current and voltage patterns that govern motor torque and speed.
Electrical and interface parameters define how the unit integrates with a plant network. A continuous output capability of 75 A sets the upper limit for motor phase current and guides cable sizing as well as cabinet thermal design. Motion commands arrive through the realtime SERCOS fiber-optic interface, allowing position and velocity updates at the drive level. Internal heat is removed by a built-in internal air blower, so designers need not add external heat sinks. Hardware identity is linked to the controller family tag DIAX04, and the hardware generation is marked as line 03, which determines compatible power supplies and firmware baselines.
The current firmware installs on version 1 hardware, so parameter memory, diagnostic codes, and service tools must match that revision. The absence of alternative catalog options simplifies spare-part logistics across multi-machine plants. Within the broader HDS Drive Controllers series, the module stays compatible with earlier supply units from Bosch Rexroth Indramat while accommodating future feature sets delivered through flash downloads. As an independent HDS Drive Controller, it can operate a single axis in stand-alone mode or share the DC link in coordinated multi-axis racks.
Frequently Asked Questions about HDS03.1-W075N-HS33-01-FW:
Q: What communication interface does the HDS03.1-W075N-HS33-01-FW drive controller use?
A: The HDS03.1-W075N-HS33-01-FW uses the SERCOS interface for command communication.
Q: Which controller family does the HDS03.1-W075N-HS33-01-FW belong to?
A: This model is part of the Bosch Rexroth Indramat DIAX04 controller family.
Q: How is the HDS03.1-W075N-HS33-01-FW drive controller cooled?
A: It features a built-in internal air blower for cooling purposes.
Q: What is the rated current for the HDS03.1-W075N-HS33-01-FW drive controller?
A: The HDS03.1-W075N-HS33-01-FW supports a rated current of 75 A.
Q: What version is the HDS03.1-W075N-HS33-01-FW drive controller?
A: This unit is designated as Version 1 according to Bosch Rexroth's model classification.
