HDS02.2-W040N-HT71-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
59 Seconds
The Bosch Rexroth Indramat HDS02.2-W040N-HT71-01-FW is a drive controller from the HDS Drive Controllers series, featuring a SERCOS command communication interface and a rated current of 40 Amps. It uses a built-in internal air blower for cooling and supports installation elevations up to 1000 meters above sea level. The controller has insulation class C per DIN VDE 0110 and a protection category of IP10.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth Indramat manufactures the HDS02.2-W040N-HT71-01-FW drive controller for the HDS Drive Controllers series. As a modular axis module, it coordinates servo power stages and closed-loop functions so that automated machinery can follow motion profiles from higher-level PLCs. The controller regulates motor behavior by processing command values and feedback signals within a multi-axis drive arrangement. The device belongs to line 02 and version 2 of the platform and is intended for use in DIAX04 multi-axis systems.
This controller exchanges setpoints and status data over the SERCOS fiber-optic interface, which supports deterministic cycle times and synchronized data exchange between the control system and the axis module. Thermal management uses a built-in air blower; by circulating cabinet air through the heat sink, the unit maintains its rated output without external fans. The power section can supply up to 40 A of continuous motor current, which suits medium-torque servo axes on packaging or handling machines. The housing has an IP10 classification in accordance with DIN 40 050, so it is intended for installation in an enclosed cabinet. Reliable operation is permitted between +5 to +45 °C, and reduced output is allowed up to a maximum of +55 °C.
For storage or shipment, the electronics tolerate temperatures from -30 to +85 °C. Installation is permitted at altitudes up to 1000 m above sea level without performance correction, which covers typical indoor industrial locations. Electrical insulation meets Class C per DIN VDE 0110 for the control circuitry and power sections that require separation from the supply potential. The unit is part of the DIAX04 family, which uses a modular multi-axis layout for coordinated motion systems. This arrangement lets one cabinet combine multiple matched axes under a common control structure.
Frequently Asked Questions about HDS02.2-W040N-HT71-01-FW:
Q: What is the rated current of the HDS02.2-W040N-HT71-01-FW drive controller?
A: The HDS02.2-W040N-HT71-01-FW features a rated current of 40 A.
Q: What communication interface does the HDS02.2-W040N-HT71-01-FW use?
A: This drive controller uses SERCOS as its command communication interface for system integration.
Q: How is the HDS02.2-W040N-HT71-01-FW cooled?
A: It includes a built-in internal air blower for cooling during operation.
Q: What insulation class does the HDS02.2-W040N-HT71-01-FW comply with?
A: The controller is classified as insulation class C according to DIN VDE 0110.
Q: What is the operating temperature range for the HDS02.2-W040N-HT71-01-FW?
A: Its permissible ambient operating temperature range is +5°C to +45°C.
