Product Description:

The HDS02.1-W040N-H drive controller is built by Bosch Rexroth Indramat for the HDS Drive Controllers series. It functions as the command section of a modular drive stack, managing motor currents and position loops so that packaging lines, material-handling stations, and CNC machines receive accurate axis regulation within an industrial automation cell. In multi-axis systems, this role helps coordinate motion between the controller and the connected power section for stable servo operation.

With a continuous output of 40 A, the controller supplies drive current for medium-power servo axes while monitoring phase balance and overload events. Thermal management is handled by a built-in air blower that forces air across the power electronics, which removes heat without external ducting. The housing has an IP 10 protection rating, so the unit must be installed inside a switch cabinet. Reliable operation is specified for surroundings between +5 to +45 °C, which suits typical industrial indoor conditions. Installation is permitted up to 1000 m above sea level before additional cooling or current reduction is required.

The module belongs to the DIAX04 family and is part of Line 02 with Version 1. When cabinet temperatures reach +55 °C, current demand must be reduced to remain within safe thermal limits. During storage or transport, it withstands a temperature range of -30 to +85 °C without damage to the unit. The insulation system is classified as C according to DIN VDE 0110, which supports operation under the thermal stress associated with cyclic industrial duty. This combination of drive control, cooling, and insulation characteristics makes the unit suitable for enclosed servo installations that require dependable motion regulation over extended operating periods.
