HDS02.2-W040N Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911284804
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
55 Seconds
The Bosch Rexroth Indramat HDS02.2-W040N is part of the HDS Drive Controllers series and has a rated current of 40 Amps with a peak current of 40 Amps. It features a built-in internal air blower for cooling and a protection category of IP10. The controller can handle a maximum input current of 37 Amps and has dimensions of 498 mm height, 50 mm width, and 308 mm depth.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Bosch Rexroth Indramat HDS02.2-W040N is a Bosch Rexroth Indramat module in the HDS Drive Controllers series. It serves as the interface between a shared supply unit and a single servo axis, shaping current and voltage to execute motion commands in packaging lines, machine tools, and material-handling cells. Designed for cabinet mounting, the controller integrates signal conditioning, fault monitoring, and bus communication so the automation system can track reference profiles without external amplifiers. It belongs to hardware line 02 and is released as version 2 within the family.
Under nominal conditions the drive delivers a rated motor current of 40 A, while its supply line can draw up to 37 A from the cabinet distribution network. Three-phase output is limited to 20 A continuous, but the stage can provide the same peak briefly for acceleration demands. The power section produces up to 500 V line-to-line at frequencies reaching 1000 Hz, giving adequate bandwidth for high-speed spindles or linear motors. A short-circuit rating of 42 000 A RMS safeguards upstream protection devices, and the peak current capacity is supported by an internal air blower. Control electronics consume 20 W, with another 20 W allocated to ±26 V signal processing. Continuous operation dissipates 125 W per axis, a figure managed inside the enclosure classed as IP10. Full performance is maintained up to 45 °C ambient, after which the output derates linearly to the 55 °C ceiling.
Physical dimensions measure 50 mm in width, 308 mm in depth, and 498 mm in height, with a mass of 6.5 kg for single-person handling at sites up to 1000 m elevation. The internal blower keeps circuitry below the specified 45 °C while dissipating 125 W. With no alternate versions, each controller delivers three-phase power and a 20 A continuous output channel.
Frequently Asked Questions about HDS02.2-W040N:
Q: What cooling method does the HDS02.2-W040N drive controller utilize?
A: This model uses a built-in internal air blower for cooling.
Q: What is the maximum output voltage of the HDS02.2-W040N drive controller?
A: The HDS02.2-W040N operates with a maximum output voltage of 500 V.
Q: What is the peak current capacity of the HDS02.2-W040N model?
A: This drive controller provides a peak current rating of 40 A.
Q: What is the short circuit current rating for the HDS02.2-W040N drive controller?
A: It is designed to handle a short circuit current up to 42000 A RMS.
Q: What is the maximum installation elevation for the HDS02.2-W040N?
A: The HDS02.2-W040N can be installed at elevations up to 1000 meters above sea level.
