HDS02.1-W040N-HS80-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships Today
The Bosch Rexroth Indramat HDS02.1-W040N-HS80-01-FW is a drive controller in the HDS Drive Controllers series and belongs to the DIAX04 controller family. It features a SERCOS command communication interface and is equipped with a built-in internal air blower for cooling. This model operates at a rated current of 40 A and is part of line 02.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HDS02.1-W040N-HS80-01-FW is a drive controller in the HDS Drive Controllers series from Bosch Rexroth Indramat. Serving as the power and regulation stage inside multi-axis machines, it rectifies incoming three-phase energy and feeds tightly controlled current to servo inverters so that conveyors, gantries, or tooling stations keep position and speed within tolerance.
The controller exchanges cyclic setpoints and diagnostic words over the SERCOS fibre-optic loop, ensuring deterministic communication with the master PLC. A power stage rated at 40 A supplies ample headroom for mid-range motors, and the loading profile is protected by fast I²t monitoring. A built-in internal air blower directs cabinet air across heatsinks to maintain semiconductor junction temperatures below specified limits, eliminating the need for external ducting. Hardware version 1 defines component layout and establishes compatibility with the matching FW firmware card inserted in the front slot.
Belonging to the DIAX04 family, the controller shares a common DC bus so regenerated energy from braking axes can be reused elsewhere on the line. Membership in Line 02 introduces revised gate-drive circuitry and expanded fault memory while preserving mounting dimensions. The modular back-plane that typifies the HDS Drive Controllers series speeds wiring because power, motor, and feedback plugs are all keyed. Diagnostic routines authored by Bosch Rexroth Indramat flag over-temperature, over-current, or communication issues before they propagate, supporting preventive maintenance programs.
Wake Industrial can arrange same-day shipping when schedules are tight, and quotations for this controller remain valid for 30 days. A free chat tool is available for general questions on type codes, fault IDs, or other technical details.
Frequently Asked Questions about HDS02.1-W040N-HS80-01-FW:
Q: What command communication interface is used in the HDS02.1-W040N-HS80-01-FW drive controller?
A: The HDS02.1-W040N-HS80-01-FW features a SERCOS command communication interface for high-speed, digital drive control.
Q: What is the rated current of the HDS02.1-W040N-HS80-01-FW drive controller?
A: This drive controller has a rated current of 40 A for reliable performance in industrial applications.
Q: Which controller family does the HDS02.1-W040N-HS80-01-FW belong to?
A: The controller family for this drive is DIAX04, ensuring compatibility with other DIAX04 system modules.
Q: What cooling method is implemented in the HDS02.1-W040N-HS80-01-FW drive controller?
A: The HDS02.1-W040N-HS80-01-FW utilizes a built-in internal air blower for cooling.
Q: What line does the HDS02.1-W040N-HS80-01-FW belong to within its series?
A: This drive controller is designated as line 02 in its series.
