The Bosch Rexroth Indramat HDS02.1-W040N-HS33-01-FW is a drive controller from the HDS Drive Controllers series. It features a SERCOS command communication interface, a rated current of 40 Amps, and uses a built-in internal air blower for cooling. This controller belongs to the DIAX04 family.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth Indramat’s HDS02.1-W040N-HS33-01-FW is a drive controller positioned in the HDS Drive Controllers series for multi-axis motion systems. Installed in a DIAX04 cabinet rack, the unit links servo drives with higher-level automation by translating command data into regulated motor current. Its role in industrial automation is to close the velocity and position loops so that connected servo motors follow programmed trajectories with consistent accuracy.
The controller exchanges setpoints and status data over the SERCOS real-time fiber-optic interface, allowing deterministic cycle times between CNC or PLC hosts and the drive. It belongs to the DIAX04 controller family, so its hardware dimensions and backplane connectors match that line. Thermal management is handled by a built-in air blower that directs cabinet air through the heat sink without external ducting. Mechanical installation is permitted up to 1000 m above sea level; operation beyond this height would reduce cooling air density and affect power output. For insulation, the power electronics use Class C materials per DIN VDE 0110, providing elevated temperature endurance for copper windings and laminated busbars.
Continuous operation is supported across an ambient range of +5 … +45 °C. The unit can remain powered until the surrounding air reaches a derated ceiling of +55 °C, although current and switching frequency must then be reduced. The housing meets IP 10 protection, so only vertically falling objects larger than 50 mm are blocked, and no liquid shielding is provided. Power stages are designed for a rated output current of 40 A, giving adequate headroom for mid-frame servo motors on packaging lines, printing presses, and material-handling axes. During logistics or storage, the module tolerates –30 to +85 °C, helping preserve functional integrity after transit through varied climates.
Frequently Asked Questions about HDS02.1-W040N-HS33-01-FW:
Q: What type of command communication interface does the HDS02.1-W040N-HS33-01-FW utilize for drive control?
A: The HDS02.1-W040N-HS33-01-FW uses a SERCOS command communication interface for precise digital drive control.
Q: What is the rated current of the HDS02.1-W040N-HS33-01-FW drive controller set by Bosch Rexroth Indramat?
A: This drive controller is rated for a current of 40 A, making it suitable for high-power applications.
Q: How is the HDS02.1-W040N-HS33-01-FW drive controller cooled during operation by Bosch Rexroth Indramat?
A: The HDS02.1-W040N-HS33-01-FW features a built-in internal air blower for its cooling method to manage internal temperature.
Q: Which controller family does the HDS02.1-W040N-HS33-01-FW drive controller belong to within the Bosch Rexroth Indramat series?
A: This model belongs to the DIAX04 controller family, integrating with other Bosch Rexroth Indramat drive modules.
Q: Which version is the HDS02.1-W040N-HS33-01-FW drive controller and are there other versions available?
A: The HDS02.1-W040N-HS33-01-FW is a version 1 unit in the HDS Drive Controllers series without other available versions.
