HDD02.1-W040N-HD01-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911271312
The Bosch Rexroth Indramat HDD02.1-W040N-HD01-01-FW is part of the HDD Drive Controllers series and weighs 8 kilograms. It features a SERCOS command interface, an internal air cooling method, and an IP10 protection rating. This controller offers a peak and rated current of 40 Amps, operates at a maximum ambient temperature of 45 °C, and measures 498 mm in height, 308 mm in depth, and 50 mm in width.
Internal Product Review
The HDD02.1-W040N-HD01-01-FW is a Bosch Rexroth Indramat HDD drive controller with a SERCOS command interface and internal air cooling. Continuous current of 15 A at 4 kHz and peak current of 40 A support strong, stable performance in demanding motion applications. IP10 protection and derated operation up to 55 °C make this controller a solid choice for industrial service.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HDD02.1-W040N-HD01-01-FW is a dual-axis drive controller produced by Bosch Rexroth Indramat as part of the HDD Drive Controllers series. It interfaces directly with servo inverters and feedback devices to regulate motor current, velocity, and position in closed-loop operation. By linking motion commands from a central PLC to the power stage that feeds each motor winding, the unit supports precise, synchronized motion in automated machining centers, packaging machines, and material-handling cells.
Motion data reach the controller over the SERCOS fiber-optic bus, allowing deterministic cycle times and simple daisy-chain wiring. When the pulse-width modulation frequency is held at 4 kHz, the device supplies a continuous armature current of 15 A. Switching at 8 kHz lowers the continuous rating to 10 A because of higher switching losses. Short bursts that overcome static friction are handled by a peak current capacity of 40 A. Thermal loading that cannot be transferred to the motor is dissipated inside the unit as 95 W/axis of power loss, while onboard logic and feedback conditioning draw 40 W of signal-processing power. With a slim 50 mm width, 308 mm depth, and 498 mm height, the controller occupies minimal panel space.
Heat generated by the power semiconductors is removed through internal air cooling, which circulates cabinet air across the heat sink, so no external blower or liquid circuit is required. The housing carries an IP10 protection rating, so the controller must be installed in an enclosed cabinet to shield it from dust or accidental contact. Rated performance is guaranteed up to 45 °C ambient, with derating allowed until 55 °C, and installation is specified for sites situated no higher than 1000 m. At only 8 kg, the module remains relatively light for cabinet installation, and its steel frame supports stable mounting next to other drive axes.
