These servo drives are used with the manufacturer’s KSM series of servomotors and are equipped with either an economy, basic or advanced control section. They come with an integrated power supply. The HCS02 series of servo drives have built-in braking resistors, while these can be added externally if needed in the HCS03 series.

HCS servo drives come with a mains voltage connection in their power sections, a motor connection and a DC bus connection. The control section of these Indramat servo drives is plugged inside the respective power sections. The servo drives are used in conjunction with the manufacturer’s HMV01 power supplies. They help to control the manufacturer’s electrical motors and monitor their operation. These drives can be deployed for single-axis as well as multi-axes drive and control tasks in handling and mounting systems, machine tools, printing, packaging, paper processing and food machines. The errors that tend to occur due to a faulty operation of the servo drive can be classified into six error clauses. We repair your broken HCS servo drives extremely fast with our industry-leading capabilities.

• HCS servo drives encompass components that are classified as Category C3 components according to IEC 61800-3 specifications.
• The servo drives must not be used in public low-voltage networks that supply power to residential areas as this can trigger high-frequency interference.
• HCS02 servo drives have an output power ranging between 1.5W to 11W for operating a motor, while HCS03 servo drives are associated with power output in the 18.5kW to 75kW range.
• These Indramat servo drives are equipped with non-volatile data memory. This memory includes the controller-specific parameter values and the drive firmware.
• HCS servo drives allow their parameters to be protected against unauthorized or accidental change using a  password. The password can be a customer password, a master password or a control password.

These HCS servo drives use drive control, administration or monitoring commands to control and activate monitoring features or complex functions. The servo drives use a KCU series connection box for connecting them with the KSM servomotors. They must be mounted only in the G1 mounting position and have IP 20 degrees of protection.

The servo drives have to be protected against conductive dirt contamination by using control cabinets with IP 54 protection rating to mount them. They portray the 3K3 climatic category during operation and have a relative humidity between 5% and 95%.
