HCS03.1E-W0210-A-05-NNNV Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911308414
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat HCS03.1E-W0210-A-05-NNNV is a drive controller from the HCS IndraDrive Controllers series. It supports a power range of 15 to 75 kW and operates on a mains voltage of 3 x AC 400 to 500V. This device features an integrated blower for air cooling and has a peak current of 210 Amps with an IP20 protection rating.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HCS03.1E-W0210-A-05-NNNV is a drive controller manufactured by Bosch Rexroth Indramat for the HCS IndraDrive Controllers series. It converts three-phase mains power into a regulated DC bus and then supplies controlled output to synchronous or asynchronous servo axes, allowing coordinated motion and energy management in automated machinery. The unit is an HCS drive controller with voltage code 05 and is intended for cabinet installation inside protected industrial environments. This arrangement lets one control stage support speed, torque, and positioning tasks across a wide range of automated machine axes.
The controller uses internal air cooling through an integrated blower, so heat is removed without external ducting. Its device peak output current reaches 210 A, giving short-term headroom for rapid acceleration or dynamic braking. Enclosure protection is rated at IP20, which limits direct finger contact and requires placement in a closed panel. The power stage accepts an input of 3 × AC 400–500 V with a tolerance of +10% / -15%, which matches common plant distribution networks. Within that supply range, the unit can handle motor groups totaling 15–75 kW, allowing the same controller size to cover different machine builds.
Energy exchange with the DC link is handled by an infeeding and regenerative power module, so surplus regenerative energy can be returned to the mains or shared with other axes. Control electronics and I/O operate from a stabilized DC 24 V supply, and an integrated brake transistor dissipates excess voltage when regenerative flow exceeds line capacity. The mechanical layout follows Design version 1, which keeps the mounting arrangement consistent with current accessories. The controller belongs to the HCS03 line series, which uses standardized mounting dimensions and connector positions across the family.
Frequently Asked Questions about HCS03.1E-W0210-A-05-NNNV:
Q: What power range is supported by the HCS03.1E-W0210-A-05-NNNV controller?
A: The HCS03.1E-W0210-A-05-NNNV drive controller supports a power range of 15 to 75 kW.
Q: What is the peak current capability of the HCS03.1E-W0210-A-05-NNNV drive controller?
A: This model has a peak current rating of 210 A, allowing for high current output during operation.
Q: What is the cooling method used in the HCS03.1E-W0210-A-05-NNNV controller?
A: Cooling is managed internally via an integrated blower, which circulates air through the unit.
Q: What level of protection does the IP20 rating give the HCS03.1E-W0210-A-05-NNNV?
A: This unit features an IP20 rating, meaning it is protected against solid objects greater than 12.5 mm and does not provide water protection.
Q: What mains voltage range does the HCS03.1E-W0210-A-05-NNNV require for operation?
A: The device is designed to operate with a mains voltage of 3 x AC 400 to 500V, with a tolerance of +10% to -15%.
