HCS03.1E-W0210-A-05-NNBN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911299239
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat HCS03.1E-W0210-A-05-NNBN is a HCS IndraDrive Controller featuring an internal air cooling method with an integrated blower. As part of the HCS03 line series, it has a peak current of 210 Amps, operates at 3-phase AC 400 to 500 Volts, and is rated at IP20. The controller supports a power range of 15 to 75 kW and can function as either an infeeding or fed power supply unit.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HCS03.1E-W0210-A-05-NNBN is a drive controller produced by Bosch Rexroth Indramat within the HCS IndraDrive Controllers series. It conditions three-phase power and manages torque, speed, and position loops for servo and induction motors. In automated packaging lines, handling systems, and general factory cells, it links the plant line supply with higher-level motion control. This allows the controller to coordinate motor response with machine commands during acceleration, deceleration, and positioning tasks.
Electrical performance is anchored by a device peak current of 210 A, giving short-term headroom for rapid acceleration and load shocks. The housing carries an IP20 rating, so the unit must be installed in a protected cabinet that provides finger-safe access and basic dust exclusion. The power section accepts 3 x AC 400...500 V +10%, -15%, letting one model operate on common industrial power systems without an external transformer. Within that input window, the converter supports motor outputs from 15 to 75 kW, allowing a single frame size to serve several machine axes. Thermal energy is removed by internal air cooling through an integrated blower, eliminating external ducting and stabilizing internal temperatures with a dedicated fan path.
The controller uses design version 1, which identifies the initial release of this hardware. Quick visual identification in multi-axis cabinets is aided by the line designation HCS03, which groups controllers sharing mounting dimensions and connector layout. The power section is configured for infeeding and fed operation, so brake and overhauling energy can return to the DC bus instead of being lost as heat during cyclic motion. Voltage code 05 matches the accepted input range and insulation clearances used by the controller.
Frequently Asked Questions about HCS03.1E-W0210-A-05-NNBN:
Q: What cooling method is used by the HCS03.1E-W0210-A-05-NNBN drive controller?
A: The HCS03.1E-W0210-A-05-NNBN controller uses internal air cooling with an integrated blower.
Q: What is the device peak current for the HCS03.1E-W0210-A-05-NNBN controller?
A: This model has a peak current rating of 210 A, supporting high-demand applications.
Q: What is the supported power range for the HCS03.1E-W0210-A-05-NNBN?
A: The HCS03.1E-W0210-A-05-NNBN is rated for use within a power range of 15 to 75 kW.
Q: What mains voltage is the HCS03.1E-W0210-A-05-NNBN compatible with?
A: This drive controller is designed for operation on a 3-phase AC mains voltage between 400 and 500V, with a +10% and -15% tolerance.
Q: What level of ingress protection does the HCS03.1E-W0210-A-05-NNBN provide?
A: The HCS03.1E-W0210-A-05-NNBN carries an IP20 rating, providing basic protection against solid objects but not against water.
