The Bosch Rexroth Indramat DKS01.1-W100A-DL05-00 is a digital servo drive from the DKS Intelligent Digital Servo Drives series, supporting a rated current of 100 Amps. It operates on a 300 V DC bus voltage, accepts 3x 230 V AC input, and can handle continuous bleeder power of 0.5 kW with a peak of 18 kW. The drive uses heat dissipation for cooling and works at a PWM frequency of 4 kHz.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DKS01.1-W100A-DL05-00 is a servo drive manufactured by Bosch Rexroth Indramat and assigned to the DKS Intelligent Digital Servo Drives series. It functions as the power interface between a motion controller and a motor, converting commanded set points into regulated current and voltage so that automated machinery can hold position, accelerate, or decelerate with closed-loop precision. This arrangement allows the drive to support repeatable motion on production equipment where stable torque control and responsive speed changes are required. It is suited to servo applications that require coordinated movement, quick response to command changes, and controlled braking behavior.
Electrical input is a three-phase supply at 3x 230 V AC (±10%), permitting connection to common factory mains. Internally, the converter maintains a regulated 300 V DC bus that feeds an IGBT bridge that switches at 4 kHz, which helps limit motor current ripple during operation. The drive accepts line frequencies from 50 Hz to 60 Hz, covering both major power grids without retuning. Continuous operation allows phase currents up to 100 A, and regenerated energy is routed to an integrated bleeder with a continuous absorption capability of 0.5 kW. Thermal energy produced by the power stage is removed through dedicated heat dissipation hardware, and conversion losses can reach 480 W under heavy load.
During rapid braking, the resistor handles peaks up to 18 kW, which helps keep the DC link voltage within safe limits during deceleration. When the inverter and auxiliaries operate at full capacity, the installation must provide up to 50 kVA, a value used for transformer and feed cable sizing. Reliable service is maintained at ambient temperatures as high as +55 °C, and operation beyond this point requires external cooling or power derating. Noise emission remains at a standard industrial level, and cooling is done by heat dissipation. Diagnostics, fieldbus processing, and protective shutdown logic are handled by the control electronics.
Frequently Asked Questions about DKS01.1-W100A-DL05-00:
Q: What is the rated current of the DKS01.1-W100A-DL05-00 servo drive?
A: The rated current for the DKS01.1-W100A-DL05-00 servo drive is 100A.
Q: What is the bleeder's continuous power rating for this drive?
A: The continuous power rating of the bleeder on this drive is 0.5 kW.
Q: What DC bus voltage does the DKS01.1-W100A-DL05-00 support?
A: The DKS01.1-W100A-DL05-00 operates with a DC bus voltage of 300 V DC.
Q: What input voltage does the DKS01.1-W100A-DL05-00 require?
A: This servo drive supports an input voltage of 3x 230 V AC with a tolerance of plus or minus 10%.
Q: What is the maximum ambient temperature for the DKS01.1-W100A-DL05-00 servo drive?
A: The maximum ambient temperature for operation is +55 °C for this model.
