Product Description:

The DKS01.1-W100A-DL03-01-FW is a servo drive module produced by Bosch Rexroth Indramat in the DKS Intelligent Digital Servo Drives series. It converts incoming line power into regulated three-phase motor output for precision motion control in machining cells, pick-and-place systems, and packaging axes. By processing motor feedback and adjusting pulse-width modulation in real time, the drive supports stable speed and torque control during changing load conditions. It also works with higher-level control systems through the DSF feedback channel, allowing coordinated response to machine commands and status signals.

Its power section accepts a three-phase supply of 3 x 230 V AC, which is rectified to an internal bus of 300 V DC for the output stage. Under rated duty, the unit delivers 100 A RMS to the connected motor, and a carrier frequency of 4 kHz shapes the PWM waveform to help reduce torque ripple. When the mechanical load rises, the converter can draw up to 11 kVA from the mains, and thermal losses can reach 480 W. That heat is dissipated through the housing, so the module depends on clear cabinet airflow rather than integrated fan cooling. A differential monitor output supplies ±10 V at 4 mA, allowing external control hardware to observe speed and error values during operation. The drive has an IP 10 enclosure and standard noise emission, so it is intended for installation inside a clean control cabinet.

For deceleration events, the integrated bleeder can absorb up to 18 kW of regenerative energy and can handle 0.5 kW continuously. The power section also tolerates momentary motor currents of up to 28 A above the nominal level before field weakening begins. Reliable operation is permitted at ambient temperatures up to 55 °C and elevations up to 1000 m when cabinet airflow is not restricted. Encoder and resolver signals remain valid over feedback cable lengths of up to 75 m, which supports installation in larger machine layouts. The drive is version 1.
