DKS01.1-W030B-DA02-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911272400
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
39 Seconds
The Bosch Rexroth Indramat DKS01.1-W030B-DA02-01-FW is a digital servo drive from the DKS Intelligent Digital Servo Drives series. It has a rated current of 30 Amps, operates with a DC bus voltage of 300 V, and supports an input voltage of 230 V AC at 50 or 60 Hz. The drive features heat dissipation cooling and reduced noise emission, with a bleeder peak power of 5 kW and an IP10 protection class.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DKS01.1-W030B-DA02-01-FW is produced by Bosch Rexroth Indramat and belongs to the DKS Intelligent Digital Servo Drives series. This closed-loop drive unit processes position and velocity commands from higher-level motion controllers and modulates power to synchronous or induction servomotors. By converting a fixed mains supply into a regulated DC link and pulse-width-modulated output, it simplifies the integration of precision axes in packaging lines, pick-and-place gantries, and general automation cells. Its control structure supports repeatable motion on machines that require steady speed regulation and accurate position response during frequent cycle changes.
Incoming power is accepted at 230 V AC with a tolerance of plus or minus 10 percent and a line frequency of 50/60 Hz. Inside the drive, a rectifier maintains a DC link of 300 V DC, and the IGBT stage switches this energy at a carrier of 18 kHz to minimize audible noise and current ripple. The power section is rated for steady motor currents up to 30 A, providing headroom for medium-frame servomotors engaged in rapid acceleration. A built-in bleeder resistor continuously dissipates regenerated energy during deceleration, helping keep the shared DC bus within a controlled operating range. Heat generated by the switching components is removed through base plate conduction and forced-air cooling, which supports stable thermal behavior during continuous operation.
The energy absorber can handle short bursts up to 5 kW, permitting high-inertia loads to stop rapidly without external braking hardware. Reliable operation is permitted between +5 °C and +45 °C, and the drive holds its output ratings anywhere below 1000 m elevation before derating is required. A housing classified as IP10 according to DIN 40050 guards against accidental contact yet relies on the control cabinet for additional protection against dust and moisture. Reduced noise emission helps limit audible sound during operation, and the cabinet-mounted design fits enclosed automation systems that already provide airflow management and external protection.
Frequently Asked Questions about DKS01.1-W030B-DA02-01-FW:
Q: What is the rated current for the DKS01.1-W030B-DA02-01-FW servo drive?
A: The DKS01.1-W030B-DA02-01-FW has a rated current of 30A, making it suitable for high-power motor applications.
Q: What is the input voltage range for the DKS01.1-W030B-DA02-01-FW?
A: This drive is engineered for operation with an input voltage of 230 V AC, with a permissible variation of ±10%.
Q: How does the DKS01.1-W030B-DA02-01-FW manage heat during operation?
A: The cooling method used for this drive is heat dissipation, which helps maintain optimal operating temperatures.
Q: What is the permissible ambient temperature range for the DKS01.1-W030B-DA02-01-FW?
A: It supports a maximum ambient temperature of +45 °C and a minimum of +5 °C for proper functioning.
Q: What protection class does the DKS01.1-W030B-DA02-01-FW offer?
A: The DKS01.1-W030B-DA02-01-FW features a protection class of IP 10 according to DIN 40050 standards.
