The Bosch Rexroth Indramat DKR04.1-W400E-BE73-01-FW is a digital intelligent AC drive controller from the DKR Drive Controllers series. It operates with a continuous current of 210 A at 4 kHz, has a rated power voltage of 3xAC 400 to 480 V, and uses an air cooling method with a built-in blower. The drive supports SERCOS command interface, handles motor feedback via digital servo and resolver feedback, and weighs approximately 150 kg.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth Indramat builds the DKR04.1-W400E-BE73-01-FW for the DKR Drive Controllers series. It is a Digital Intelligent AC drive controller intended for high-power servo axes in metal-cutting centers, press lines, and automated handling equipment. In these systems, the controller converts incoming electrical power into regulated motor current so the axis can follow commanded speed and torque values with repeatable response. The unit uses an external bleeder with a rigid DC bus, so regenerated energy is sent to a brake resistor through an integrated chopper and DC-link overvoltage is limited during rapid deceleration or load reversals.
Data exchange with the machine PLC is handled over the SERCOS interface, giving deterministic cyclic control of velocity and torque loops. At a 4 kHz switching frequency, the drive supplies a continuous current of 210 A and continuous usable shaft power of 93 kW. The logic electronics are powered by a separate AC 230 V ±10% control supply, while the power stage connects to a mains input of 3×AC 400–480 V with the same tolerance. This split supply arrangement supports stable control operation while the main power section handles motor demand. Cooling is provided by a built-in air blower that keeps semiconductor temperatures within limits. Line series 04, design version 1, and function module version 01 indicate the product generation.
During dynamic peaks, the inverter can deliver 282 A to overcome momentary inertia or friction spikes. Under these conditions, it releases up to 2500 W of heat, which must be removed by the cabinet ventilation system. Digital servo and resolver feedback channels allow the controller to operate with a wide range of Bosch Rexroth and third-party motors without extra interface boards. That feedback flexibility supports use in retrofits as well as in new multi-axis installations where motor types may vary by machine section. Despite its power density, the device weighs 150 kg, which should be considered for panel support and lifting.
Frequently Asked Questions about DKR04.1-W400E-BE73-01-FW:
Q: What types of motor feedback are supported by the DKR04.1-W400E-BE73-01-FW drive controller?
A: The DKR04.1-W400E-BE73-01-FW supports both digital servo and resolver motor feedback for precise control and monitoring.
Q: What is the bleeder configuration for the DKR04.1-W400E-BE73-01-FW?
A: This drive controller uses an external bleeder with brake chopper and a rigid DC bus configuration.
Q: What command interface does the DKR04.1-W400E-BE73-01-FW use?
A: The DKR04.1-W400E-BE73-01-FW operates with a command interface based on the SERCOS protocol for communication with control systems.
Q: How is the DKR04.1-W400E-BE73-01-FW drive controller cooled?
A: Cooling for this model is provided by air using a built-in blower to maintain optimal operating temperatures.
Q: What is the rated power voltage range for the DKR04.1-W400E-BE73-01-FW?
A: The DKR04.1-W400E-BE73-01-FW is rated for a power voltage of 3-phase AC 400 to 480 V, with a tolerance of plus or minus 10%.
