Product Description:

The DKR04.1-W400N-BE23-01-FW drive controller is built by Bosch Rexroth Indramat as part of the DKR Drive Controllers series. It supplies regulated three-phase power to large synchronous or induction servo axes, allowing centralized or distributed automation cells to coordinate motion over a shared DC link. By converting incoming line energy into pulse-width-modulated output, the unit supports precise speed, torque, and position control for packaging lines, gantries, and machining centers.

This controller exchanges setpoints and diagnostics through the SERCOS interface, so deterministic fiber-optic telegrams synchronize each axis with the main PLC. Internal thermal management relies on Air (built-in blower); the integrated fan moves cabinet air across the heat sink to keep semiconductor temperatures within limits. For position feedback the unit accepts Digital servo and resolver feedback, enabling mixed encoder types on the same channel. The power stage follows a No bleeder arrangement that operates without a brake chopper; braking energy is therefore not burned in resistors. Instead, the shared link remains a rigid DC bus, so regenerated power must be absorbed by other motoring drives or an external dissipative module.

Configuration codes clarify compatibility details. Hardware conforms to Design Version 1, fixing terminal layouts and option slots to the first mechanical revision. Control algorithms are tagged as Function Numeric Version 01, which defines the parameter set loaded during commissioning. Within the family tree the amplifier belongs to Line Series 04, placing its current and voltage ratings among the lower-power members of the platform. Units released under Bosch Rexroth Indramat quality procedures follow these designations so replacement controllers integrate into existing SERCOS rings and rigid DC links without rewiring.
