DKR03.1-W200N-BE37-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911266988
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat DKR03.1-W200N-BE37-01-FW is a digital AC drive controller from the DKR Drive Controllers series. It features a continuous power of about 35 kW at 4 kHz, and uses air cooling with a built-in blower. The drive controller supports a SERCOS command interface and provides digital servo and resolver motor feedback.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DKR03.1-W200N-BE37-01-FW is an intelligent AC drive controller manufactured by Bosch Rexroth Indramat for the DKR Drive Controllers series. By monitoring motor position and current in real time, the unit coordinates high-power servo axes in machining centers, packaging lines, and material-handling cells. In an automation cabinet, the controller converts fixed input power into precision-regulated three-phase output, closes feedback loops, and exchanges motion commands with the PLC. The architecture combines power electronics and control logic in one enclosure.
Motion commands reach the controller through the SERCOS interface, allowing fiber-optic communication with centralized controls. At a 4 kHz switching frequency, the power stage can deliver 92 A of armature current, which supports up to 35 kW of shaft power when the unit is paired with a matched motor. Internal logic is supplied by a separate AC 230 V control circuit, so parameter memory and diagnostics remain active even if line power is isolated. Thermal energy is removed by a built-in air blower, so no external ducting is required. The DC bus is configured without a brake chopper, so surplus energy is handled through the drive regeneration path.
In transient moves, the drive can source up to 141 A, providing extra current for rapid acceleration and deceleration beyond the continuous rating. The power section accepts a three-phase supply of 3×AC 400–480 V ±10%, making it suitable for common industrial power systems. At peak throughput, the assembly releases 1200 W of heat that must be removed by cabinet ventilation. With a transport mass of 49 kg, the unit is intended for floor-standing enclosures. The unit is Line 03, design 1, and function module 01. A digital resolver feedback channel maintains positional accuracy under changing loads.
Frequently Asked Questions about DKR03.1-W200N-BE37-01-FW:
Q: What cooling method is used by the DKR03.1-W200N-BE37-01-FW drive controller?
A: This model uses air cooling via a built-in blower to manage heat during operation.
Q: What command interface is provided on the DKR03.1-W200N-BE37-01-FW?
A: The drive features a SERCOS interface as its command input for efficient communication with control systems.
Q: What is the continuous current capacity of the DKR03.1-W200N-BE37-01-FW at 4 kHz?
A: The continuous current supported at 4 kHz is rated at 92 A.
Q: What type of motor feedback does the DKR03.1-W200N-BE37-01-FW support?
A: Motor feedback on this controller is handled by both digital servo and resolver feedback signals.
Q: What is the required rated power voltage for the DKR03.1-W200N-BE37-01-FW drive controller?
A: The rated power voltage requirement is 3-phase AC 400 to 480 V, with a tolerance of plus or minus 10%.
