The Bosch Rexroth Indramat DKR03.1-W200B-BE30-01-FW is part of the DKR Drive Controllers series and is a digital intelligent AC drive controller. It features a continuous drive power of about 35 kW at 4 kHz and a peak current rating of 141 Amps. This controller includes an internal bleeder, supports SERCOS command interface, and weighs approximately 49 kilograms.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DKR03.1-W200B-BE30-01-FW belongs to the DKR Drive Controllers series produced by Bosch Rexroth Indramat. It is a digital intelligent AC drive controller that converts three-phase mains power into variable-frequency output for induction or servo motors used in industrial automation. The unit integrates power electronics, feedback evaluation, and an internal brake resistor, so a separate braking module is not required. Through the SERCOS interface, it exchanges velocity, torque, and positioning data with higher-level motion controllers for coordinated multi-axis applications. This integrated layout keeps the cabinet arrangement simpler and reduces the need for additional braking hardware beside the controller.
At a 4 kHz switching frequency, the drive supplies a continuous current of 92 A, which supports mechanical loads that demand sustained torque. Its silicon power section can continuously furnish 35 kW of electrical output, while short-term overloads are handled by a peak capability of 141 A. The power stage is designed for a mains range of 3 x AC 400 to 480 V ± 10%, and the logic circuitry is energized from an auxiliary supply of AC 230 V ± 10%. The W200 designation places the unit in the 200 A current class, and an internal bleeder diverts regenerated energy into the built-in resistor whenever the DC link rises above its threshold. Thermal losses are removed by forced-air cooling that uses an integrated blower to keep semiconductor temperatures within safe limits.
The brake resistor can dissipate 1 kW continuously and absorb up to 150 kWs of braking energy during rapid deceleration cycles. Overall heat produced by the power devices and control electronics reaches 1200 W, which helps with cabinet ventilation planning. Mechanical handling is straightforward because the drive weighs 49 kg. Digital servo and resolver feedback channels permit mixed-encoder operation, so the controller can work with different motor feedback devices without a separate interface module. The controller is in line series 03 with design version 1 and function module version 01.
Frequently Asked Questions about DKR03.1-W200B-BE30-01-FW:
Q: What type of bleeder configuration does the DKR03.1-W200B-BE30-01-FW controller feature?
A: The DKR03.1-W200B-BE30-01-FW is equipped with an internal bleeder for handling excess energy during braking events.
Q: What command interface does the DKR03.1-W200B-BE30-01-FW use?
A: This drive controller utilizes a SERCOS interface as its command interface, providing digital communication with automation systems.
Q: What is the continuous current at 4 kHz for the DKR03.1-W200B-BE30-01-FW?
A: At a switching frequency of 4 kHz, the DKR03.1-W200B-BE30-01-FW delivers a continuous current of 92 A.
Q: What type of motor feedback is supported by the DKR03.1-W200B-BE30-01-FW controller?
A: The DKR03.1-W200B-BE30-01-FW provides digital servo and resolver feedback for precise motor control and position detection.
Q: How is the DKR03.1-W200B-BE30-01-FW cooled during operation?
A: This unit uses air cooling with a built-in blower to dissipate heat and maintain stable operation.
