DKR02.1-W200N-BE42-03-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911286628
The Bosch Rexroth Indramat DKR02.1-W200N-BE42-03-FW is a digital intelligent AC drive controller from the DKR Drive Controllers series. It has a rated power voltage of 3-phase AC 400 to 480 V and a control voltage of AC 230 V. This drive supports a continuous current of 120 A at 4 kHz, provides approximately 47 kW of continuous power, and weighs about 104 kg.
Internal Product Review
The DKR02.1-W200N-BE42-03-FW is a digital intelligent AC drive controller with a SERCOS interface and digital servo/resolver feedback. Continuous output at 4 kHz is impressive, with 120 A current capacity and approximately 47 kW of drive power for demanding motion applications. Built-in blower cooling supports stable thermal performance, making the DKR drive controller a strong choice for high-load automation systems.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Bosch Rexroth Indramat DKR02.1-W200N-BE42-03-FW is a digital intelligent AC drive controller in the DKR Drive Controllers series. Installed in an automation cabinet, it links incoming power, the DC bus, and the motion-control network so the connected axis can receive regulated motor current. It is intended for large servo systems that need precise current control rather than simple line switching. This role lets the controller maintain stable speed, torque, and position control when mechanical demand changes during acceleration, deceleration, or steady-state operation.
Communication is handled through the SERCOS interface, which carries cyclic setpoints and diagnostic data over fiber-optic links for deterministic motion exchange. The controller delivers a continuous output of 120 A at a 4 kHz switching frequency and can support about 47 kW of mechanical power in suitable servo applications. Its internal logic and control stages are supplied by a separate AC 230 V ± 10 % source, which helps keep the control electronics stable during load changes. Thermal energy is removed by a built-in air blower, and the power stage can reach a peak of 141 A during acceleration or other short-term demand.
The power section accepts 3×AC 400–480 V ± 10 % mains, allowing the unit to operate from common industrial three-phase supplies. During full-load operation, the heat sinks dissipate about 1600 W, so the cabinet must provide enough airflow and internal clearance to move heat away from adjacent equipment. The controller has an approximate mass of 104 kg, which affects panel support and mounting layout. The DC link is built without an internal brake chopper or integrated bleeder, so regenerated energy must be managed elsewhere on the shared bus. Motor position control uses digital servo and resolver feedback, allowing accurate closed-loop response in multi-axis systems.
