The Bosch Rexroth Indramat DKR02.1-W200B-BE32-01-FW is part of the DKR Drive Controllers series and has a current rating of 200 Amps. It features a SERCOS command interface, digital servo and resolver motor feedback, and an internal bleeder with a brake resistor continuous power of 1.5 kW. The drive has an air cooling system with a built-in blower and weighs approximately 104 kg.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DKR02.1-W200B-BE32-01-FW is a Digital Intelligent AC Drive Controller built by Bosch Rexroth Indramat within the DKR Drive Controllers series. The product is part of Line 02, uses design version 1, and incorporates function module version 01. This controller supplies regulated three-phase power to large servo motors and manages positioning tasks through integrated processing and feedback channels, making it a central component in automated machine tools, presses, and handling systems. It is intended for industrial axes that require stable current regulation and consistent motion response during continuous operation.
The unit communicates with higher-level PLCs through a SERCOS interface, allowing deterministic command exchange and real-time status updates. At a 4 kHz switching frequency, the controller delivers a continuous output current of 120 A and continuous power of 47 kW. For short acceleration bursts, the controller can deliver a peak current of 141 A, giving additional torque headroom before thermal limits intervene. Internal losses, fan power, and bleeder dissipation combine to a total heat output of 1600 W, so cabinet ventilation must remove this heat to keep electronic components within the operating temperature range. The controller accepts digital servo and resolver feedback channels, and power is supplied from a three-phase mains connection rated at 400 to 480 V AC ±10%.
An internal brake resistor continuously absorbs up to 1.5 kW of regenerative energy released during deceleration, and it can store a maximum of 240 kWs before thermal protection activates. Control electronics draw auxiliary power from a separate AC 230 V ±10% source, which allows communication activity and stored settings to remain available when the main contactor is open. Forced-air cooling is provided by a built-in blower to support heat removal during sustained operation. The overall assembly weighs 104 kg, which affects panel layout and handling during installation. This separate control supply also supports orderly system behavior during shutdown states or brief interruptions of the main power path.
Frequently Asked Questions about DKR02.1-W200B-BE32-01-FW:
Q: What type of bleeder configuration is used in the DKR02.1-W200B-BE32-01-FW drive controller?
A: The DKR02.1-W200B-BE32-01-FW features an internal bleeder for managing excess energy during braking cycles.
Q: What command interface does the DKR02.1-W200B-BE32-01-FW support?
A: This model uses a SERCOS interface for communication and command input.
Q: What is the continuous power output of the DKR02.1-W200B-BE32-01-FW at 4 kHz?
A: The DKR02.1-W200B-BE32-01-FW can deliver a continuous power output of approximately 47 kW at 4 kHz.
Q: What cooling method does the DKR02.1-W200B-BE32-01-FW use?
A: Cooling is provided by a built-in blower using forced air on this drive controller.
Q: What is the rated power voltage range for the DKR02.1-W200B-BE32-01-FW?
A: This controller accepts a rated power voltage of 3-phase AC 400 to 480 V with ±10% tolerance.
