Product Description

The DDS02.2-W015-BT20-01-FW drive controller manufactured by Bosch Rexroth works with synchronous, inductance linear, synchronous linear and inductance AC motors. This controller is a good choice for use in robotics-related applications. The product is connected to the motor using a power cable and a feedback cable. The device supports connection to a power supply with a regulated 24VDC voltage. The unit should be properly assembled, installed, transported and stored for safe and optimum operation. Its earth wire must be checked for permanent connection to the electrical components in accordance with the connection diagram after the installation process is complete.

The product should be worked on only after a few minutes of switching it off so that its capacitors get discharged fully. The device is meant to be protected against indirect contact as per DIN 50178 specifications. The unit may move dangerously at any point of time during operation due to faulty wiring or software errors of the motor connected to it. Its power connection must be isolated through an emergency stop circuit for protection against unintentional startups. The controller is supposed to be installed only in commercial machinery. This product operates at an ambient temperature of 0°C to 45°C with rated data.

The device has a weight of approximately 7.5kg. The unit features protection against penetration of solid objects with diameters of more than 50mm. Its energy loss is based on the continuous current of the connected motor in standstill mode. The controller must be installed only in a vertical orientation. This product should encompass a clearance distance of at least 80mm above and below it inside the associated control cabinet. The device must use plugin clamps for its signal lines. It can be connected to an adjacent rail by using DC bus conductor rails. The drive controller with one-year backup support can be dispatched to any worldwide destination.
