Product Description

The Bosch DDS02.2-W015-BE31-01-FW is a digital drive controller. It is used for motor control in industrial applications. The rated current output of the controller is 15 Amps. The controller support two motor feedback methods: resolver feedback and digital servo feedback. Each DDS controller features a command communication module. The command module on the DDS02.2-W015-BE31-01-FW controller supports SERCOS. Other options for command modules include Analog interface and single-axis positioning control. The DDS02.2-W015-BE31-01-FW dissipates heat inside the control cabinet. The cooling inlet is located at the bottom side of the controller. The cooling outlet is located at the top side of the controller. To maintain an appropriate level of inter-device separation, large cabinets have to be used. The minimum amount of required spacing at the top and bottom sides of the mounted controller is 80 millimeters.

The minimum amount of required spacing at the front of the mounted controller is 40 millimeters. Dimensions of the DDS02.2-W015-BE31-01-FW controller are 355 x 325 x 105 millimeters. The controller is designed for vertical mounting. The slots for optional and mandatory modules are located on the front panel. DC power supplies that deliver 24 Volts DC regulated output can be used to power the controller. The DDS02.2-W015-BE31-01-FW weighs approximately 7.5 kilograms. Applications for drive systems comprised of DDS controllers and compatible motors include textiles, packaging machines and printing machines. Only qualified personnel may work on the controller and associated equipment. Only spare parts approved by Bosch should be used. The controller is intended for use in machines designed for commercial use. System startup is permitted if the machine in which the controller is installed complies with EC directive 90/392/EWG. Technical data and installation conditions for the DDS02.2-W015-BE31-01-FW as outlined in the product documentation must be maintained.
