The DDS02.2-W015-BE30-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 15 A rated current, and Digital Servo and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

DDS02.2-W015-BE30-01-FW

  • Rated 4.5 (36 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911280445
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The DDS02.2-W015-BE30-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 15 A rated current, and Digital Servo and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.2-W015-BE30-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch DDS02.2-W015-BE30-01-FW is a DDS02.2 series digital drive controller. The controller has a modular architecture with a basic unit that has slots for mandatory and optional hardware modules. The mandatory hardware modules include a software module and a command module. Three slots are available for optional modules. The combination of optional modules and firmware can be used to adapt the controller to a wide range of customer applications. The command module on the DDS02.2-W015-BE30-01-FW supports the SERCOS standard. This standard enables serial communication in real-time between compatible control devices. The physical medium used by the technology is fiber-optics. The data transmission speeds supported by the SERCOS standard include 2 Mbps and 4 Mbps. Advanced versions of the SERCOS standard are compatible with Ethernet and support up to 100 Mbps full duplex communication.

Firmware for the DDS02.2-W015-BE30-01-FW controller is ordered as a separation subposition. It is housed on the software module which is the second mandatory module. The software module also houses the programmed drive parameters. In case of drive malfunction or failure, this module can be easily moved to another drive. This helps to minimizes system downtime and prevents extended production losses. Rated output current of the DDS02.2-W015-BE30-01-FW is 15 Amps. The controller supports both digital servo feedback and resolver feedback. Heat dissipated by the DDS02.2-W015-BE30-01-FW during operation is dissipated inside the control cabinet. Therefore large cabinets have to be used for maintenance of ambient temperature. The DDS series to which the DDS02.2-W015-BE30-01-FW belongs is compatible with a wide range of Bosch motors including those from the MDD, MKD and 1MB motor families. Only professionally trained personnel should be involved in the handling and installation of the DDS02.2-W015-BE30-01-FW drive.

DDS02.2-W015-BE30-01-FW Documents

  • DDS022W015BE3001FW
  • DDS02 2 W015 BE30 01 FW
  • dds02.2-w015-be30-01-fw
  • DDS2.2-W015-BE30-01-FW

DDS02.2-W015-BE30-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo and Resolver Feedback
Rated Current: 15 A
