DDS02.2-A100-BE37-01-FW

  • Rated 4.7 (21 total ratings)
  • MPN: R911271644
  • Stock: In-Stock, Ships 3-5 Days
  • Factory New Pricing Available! Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The DDS02.2-A100-BE37-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 100 A rated current, and Digital Servo and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.2-A100-BE37-01-FW

  • Rated 4.7 (21 total ratings)
  • MPN: R911271644
  • Stock: In-Stock, Ships 3-5 Days
  • Factory New Pricing Available! Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The DDS02.2-A100-BE37-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 100 A rated current, and Digital Servo and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.2-A100-BE37-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS02.2-A100-BE37-01-FW servo drive features an H1 display that shows its current operating state. If the drive is set to the operating mode but has no command activated, the term 'AF' is displayed. This device from Bosch Rexroth has a current rating of 100A. The product must be installed in a control cabinet. It has a line code of 2.It makes use of a supply unit to monitor the DC bus voltage. The unit is capable of monitoring if it can comply with the set command value when the control loop is closed.

The drive indicates an F229 quadrant error if the motor encoder interface identifies a hardware error. The unit supports the insertion of plug-in modules in slots U1 to U4. The fifth U5 slot is reserved for the insertion of the software module. The device must be mounted only after removing the faceplate and the rating plate. It utilizes a SERCOS interface for command communications. This interface is inserted in the first slot and helps to use the drive along with SERCOS compatible controls through a fiber optic cable. The servo drive comes with a one-year warranty period.

The product can be operated at a maximum temperature of 55°C with derated data. The unit has a function ID code of 01 that is determined and fixed by the manufacturer. The device supports connection to supply units with a regulated 24V rating. It can be used with inductance, linear and synchronous motors. The drive must not be operated with the manufacturer’s TVM 1.2 supply unit because of its unregulated voltage. The product can be used as a rapid response drive. It must be properly assembled, installed, operated, transported and stored for its safe and effective operation. The servo drive can be delivered globally through our partnered companies such as FedEx, DHL and UPS.

DDS02.2-A100-BE37-01-FW Documents

  • DDS022A100BE3701FW
  • DDS02 2 A100 BE37 01 FW
  • dds02.2-a100-be37-01-fw

DDS02.2-A100-BE37-01-FW Technical Specifications

Cooling: External Cooling
Motor Feedback: Digital Servo and Resolver Feedback
Rated Current: 100 A
