DDS02.1-W150-DS50-00-FW

  • Rated 4.5 (13 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911269727
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W150-DS50-00-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 150 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

DDS02.1-W150-DS50-00-FW

  • Rated 4.5 (13 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911269727
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W150-DS50-00-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 150 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-W150-DS50-00-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS drive system is a modular and highly flexible drive system by Bosch Rexroth designed for a wide range of industrial applications. The highly efficient drive controllers in the drive system can be combined with the MDD and MKD synchronous motors and the LAR and LAF linear inductance motors to produce rapid response drives. The applications of these drives include machine tools, textile industries, and printing and packaging machinery.

The DDS02.1-W150-DS50-00-FW is a DDS drive controller designed by Bosch Rexroth. It is a component of the DDS drive system featuring the heat technology system for heat dissipation. The cooling airflow in this heat dissipation method is within the control cabinet housing the drive controller. Consequently, a large control cabinet with air conditioning has to be used. The Ingress Protection rating of the control cabinet is IP 10 as per DIN 40 050. It houses the drive controller and its supply unit and protects them from solid extrinsic objects over 50mm in diameter. The drive controller itself has an IP rating of IP 20 as it is protected from the entry of objects larger than 12mm.

With a bus voltage of 300V and ±15% tolerance, the DDS02.1-W150-DS50-00-FW can be operated. Its current rating is 150A, and it is equipped with a SERCOS interface. With this plugin module, digital drives with SERCOS compatible controls can be operated via a fiber optic cable. It is also compatible with motors with digital servo feedback. The permissible ambient temperature for the operation of the drive controller is between 0oC and 45oC. Its maximum permissible relative air humidity is 95% and it should be installed at a maximum height of 1000m.

DDS02.1-W150-DS50-00-FW Documents

  • DDS021W150DS5000FW
  • DDS02 1 W150 DS50 00 FW
  • dds02.1-w150-ds50-00-fw
  • DDS2.1-W150-DS50-00-FW

DDS02.1-W150-DS50-00-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 150 A
