DDS02.1-W150-DS37-00-FW

  • Rated 4.6 (39 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911264667
    In-Stock, Ships 1-2 Days

Current response time:

6 Minutes 14 Seconds

DDS02.1-W150-DS37-00-FW is a controller designed for industrial motor control. Its rated output is 150 Amps. The controller supports SERCOS communication.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

DDS02.1-W150-DS37-00-FW is a modular DDS series controller with 150 Amps rated output. It is produced by Bosch for industrial motor control applications. Bosch motor series that are compatible with DDS controllers include MDD and MKD synchronous motors, and LAR, and LAF linear motors. Firmware for the unit must be ordered as a separate item. The firmware is stored on the software module that is installed in slot U5 of the controller basic unit. In addition to firmware, the operating parameters for the controller are also stored on the software module. The contents of a software module can be copied to other modules to speed up controller commissioning. Another benefit of the modular approach is that software modules from faulty or malfunctioning units can be moved to replacement units. This allows minimization of system downtime, and ensures business continuity. Bosch has designed the DDS02.1-W150-DS37-00-FW controller with an IP20 rated housing. It mounts vertically and measures 355 x 105 x 325 millimeters. Spacing around the controller helps to ensure smooth flow of air required for heat dissipation. Bosch recommends minimum 40 millimeters spacing on the front side of the unit and 80 millimeters on the top and bottom sides. The specified ambient temperature for rated operation is 0 to 45 degrees Celsius. Bosch permits operation with derated data at ambient temperature of up to 55 degrees Celsius. The DDS02.1-W150-DS37-00-FW controller supports digital servo feedback. It is equipped with SERCOS communication module. SERCOS is a standard for high-speed serial communication between SERCOS-compatible devices. Rated voltage for the DC bus on the unit is 300 Volts. Weight of the unit is approximately 7.5 kilograms. Only trained personnel should install and operate the controller.

DDS02.1-W150-DS37-00-FW Technical Specifications

Product type: Drive controller
Firmware: Separate
Protection rating: IP20
Current rating: 150 Amps
Mounting: Vertical
Product line: DDS
Compatible motors: MKD, MDD, LAR, LAF
Cooling: Air cooled
Feedback : Digital servo feedback
Communication: SERCOS

Frequently Asked Questions about DDS02.1-W150-DS37-00-FW


Q: What is SERCOS?

A: SERCOS is a standard for high-speed serial communication over fiber optic media.

Q: Can the controller be deployed outdoors?

A: With an IP20 rating, the controller must be installed in a cabinet for outdoor use.

Q: What are ambient limits for controller use?

A: The maximum permitted ambient temperature with rated data is 45 degrees Celsius and the maximum altitude is 1000 meters.

Q: What are the controller dimensions?

A: Dimensions of the controller are 355 x 105 x 325 millimeters.

Q: What are spacing requirements?

A: Bosch recommends 80 millimeter spacing on the top and bottom sides and 40 millimeter spacing in front of the unit.

Internal Product Review

  • ‘‘DDS02.1-W150-DS37-00-FW is a powerful drive controller with 150 Amps rated output and support for SERCOS communication.’’
