The DDS02.1-W100-DA02-01-FW Servo Drive is manufactured by Rexroth Indramat Bosch. This drive has a Internal cooling system with a Rated Current of 100A and Digital Servo Motor Feedback.

DDS02.1-W100-DA02-01-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911270155
  • Stock: Call for Quote
The DDS02.1-W100-DA02-01-FW Servo Drive is manufactured by Rexroth Indramat Bosch. This drive has a Internal cooling system with a Rated Current of 100A and Digital Servo Motor Feedback.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a DDS02.1-W100-DA02-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Rexroth Indramat are industrial leaders in manufacturing advanced drive and control products. Their line of products includes servo drives, drive controllers and embedded PCs. The products offered by Rexroth Indramat are well built, have high performance and are power efficient. The DIAX 02 drive controllers manufactured by the company are offered under their DDS series.

The DDS02.1-W100-DA02-01-FW belongs to the DDS series of DIAX 02 drive controllers. This controller includes software modules, plugin modules and the base unit of the controller. The DDS02.1-W100-DA02-01-FW is a 2nd series drive controller having internal cooling. The internal cooling of the unit eliminates the need for additional heat exchanges. Heat exchangers can be installed when the DDS02.1-W100-DA02-01-FW is operated at temperatures beyond its permissible temperature. This unit has a current rating of 100 A and has a digital servo feedback. This drive controller also has a SERCOS interface in its communication module. The function ID for the DDS02.1-W100-DA02-01-FW is 02 and it is the 1st version of function ID. The firmware for this unit needs to be purchased separately as it is not shipped with the base unit.

The DDS02.1-W100-DA02-01-FW is not protected against water and dust and has an IP 20 rating. It is strongly recommended to install this drive controller in a control cabinet having high IP ratings. The DDS02.1-W100-DA02-01-FW can be operated to a maximum of 55°C with derated data and up to 45°C with rated data. The maximum allowable elevation to install this unit is 1000 m. The DDS02.1-W100-DA02-01-FW has a configuration rating plate which can be used to determine which components are fitted in which slots. This also enable correct part ordering in an event of a breakdown. The DDS02.1-W100-DA02-01-FW can be shipped to any address globally with a one-year warranty period from Wake Industrial.

DDS02.1-W100-DA02-01-FW Documents

  • DDS021W100DA0201FW
  • DDS02 1 W100 DA02 01 FW
  • dds02.1-w100-da02-01-fw

DDS02.1-W100-DA02-01-FW Technical Specifications

Cooling: Internal
Motor Feedback: Digital Servo
Rated Current: 100A
