The DDS02.1-W025-RS16-02-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 25 A rated current, and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

DDS02.1-W025-RS16-02-FW

  • Rated 4.4 (21 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911271724
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W025-RS16-02-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 25 A rated current, and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-W025-RS16-02-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch Rexroth DDS02.1-W025-RS16-02-FW is a digital drive controller. It is designed for motor control in industrial applications. When unused, the controller should be stored in a dry, dust-free and shock-free environment where the ambient temperature is between -30 and 85 degrees Celsius. Shock-damping supports should be used during transport if required. The DDS02.1-W025-RS16-02-FW controller is modular in design. The basic unit can be adapted for different functions with the use of various plug-in modules. A configured drive controller is made up of a basic unit, plug-in modules, software module and firmware. The drive controllers are delivered by Bosch already configured in terms of the desired function. A rating plate is attached to the front of the device and can be used to verify the specifications. The software module installed in slot U5.

The command communication module, which for the DDS02.1-W025-RS16-02-FW is SERCOS, installs in slot U1. Slot U2, U3 and U4 are available for auxiliary plug-in modules. Cooling for the DDS02.1-W025-RS16-02-FW is implemented with heat technology: the heat dissipates within the control cabinet. Therefore large control cabinet and air conditioning may be required for proper cooling. Power section specifications for the DDS02.1-W025-RS16-02-FW include 300 Volts DC bus voltage and 24 Volts DC input voltage. The controller can only be powered from regulated DC supplies. The basic unit consumes 500 milliamps of current. The rated output of the DDS02.1-W025-RS16-02-FW is 25 Amps. The controller supports resolver feedback. Weight of the DDS02.1-W025-RS16-02-FW is approximately 7.5 kilograms. Reliable and safe operation is dependent on proper installation. Therefore only qualified personnel with proper training should assemble, install and operate the drive controller. Only spare parts that are approved by Bosch should be used.

DDS02.1-W025-RS16-02-FW Documents

  • DDS021W025RS1602FW
  • DDS02 1 W025 RS16 02 FW
  • dds02.1-w025-rs16-02-fw
  • DDS2.1-W025-RS16-02-FW

DDS02.1-W025-RS16-02-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Resolver Feedback
Rated Current: 25 A
