DDS02.1-W015-DS04-03-FW

  • Rated 4.5 (37 total ratings)
  • MPN: R911270735
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W015-DS04-03-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 15 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-W015-DS04-03-FW

  • Rated 4.5 (37 total ratings)
  • MPN: R911270735
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W015-DS04-03-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 15 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-W015-DS04-03-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch Rexroth DDS02.1-W015-DS04-03-FW is a modular drive controller. The basic unit of the controller has empty slots that can be filled with modules to suit any particular application. There are five slot on the basic unit: two are reserved and three can be used for plug-in modules. The reserved slots include a slot for the software module and a slot for the command communication module. The software module is used to store the firmware and operating parameters for the drive. A software module can be copied to other software modules which can then be installed on drives to speed up the commissioning process. The software module from a faulty drive can be moved to a replacement drive to speed up troubleshooting and minimize the machine downtime.

The firmware for the DDS02.1-W015-DS04-03-FW drive has to be ordered as a separate subposition. The command communication module installed on the drive is SERCOS. The rated current of the drive is 15 Amps. The drive also supports digital servo feedback. DDS drives are compatible with MDD servo motors. The drive controller – servo motor combination forms an effective drive system that is well suited to applications such as handling systems, robotics, textile machines and packaging machines. A signal processor on the DDS02.1-W015-DS04-03-FW is responsible for all control, monitoring and diagnostics functions. The DDS02.1-W015-DS04-03-FW is capable of very high-resolution measurement of the motor rotor position. DS04 is the name used for an AC drive with SERCOS interface and direct position sensing. A RS-232 interface is provided on the front panel for interfacing with a VT100 terminal or a computer. The drive nameplate is also located on the front panel of the DDS02.1-W015-DS04-03-FW drive.

DDS02.1-W015-DS04-03-FW Documents

  • DDS021W015DS0403FW
  • DDS02 1 W015 DS04 03 FW
  • dds02.1-w015-ds04-03-fw

DDS02.1-W015-DS04-03-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 15 A
