DDS02.1-A050-DS24-03-FW

  • Rated 4.5 (28 total ratings)
  • MPN: R911267919
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A050-DS24-03-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 50 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-A050-DS24-03-FW

  • Rated 4.5 (28 total ratings)
  • MPN: R911267919
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A050-DS24-03-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 50 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-A050-DS24-03-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS02.1-A050-DS24-03-FW from Rexroth Indramat is a digital A.C. drive controller in DDS controllers' Series 2 product line. By design, this unit is intended for the efficient control of servo motors. It has an approximate mass of 11 kg, a modular design, and can be used for several drive applications. This unit comes pre-configured and includes all of the necessary software and hardware. Unlike other models, the firmware of the DDS02.1-A050-DS01-02-FW is purchased as a separate sub-item.

The DDS02.1-A050-DS01-02-FW is mounted in an I.P. 10-rated air control cabinet, and it features a unique cold cooling technology that draws air from outside the cabinet and discharges all of its heat outside the cabinet. Also, the command interface module featured on the DDS02.1-A050-DS24-03-FW is the SERCOS-type. It uses a digital servo motor feedback, and its D.C. bus voltage rating is 300 Volts (± 15 %). The R.H. value of this unit is max. at 95 % and min. at 5 %. In addition, its design and structural makeup conform with the IP 20 material protection class, as per EN 60 529. The energy loss in the control cabinet of this A.C. drive controller is rated at 54 Watts.

The function I.D of the DDS02.1-A050-DS24-03-FW is 24, and its function I.D version is 03. The acceptable ambient air temperature suitable for this unit is within the range of 0 degrees C – 45 degrees Celsius. If operated at reduced data, the max. admissible temperature is rated at 55 degrees Celsius. The allowable mounting elevation is 1000 meters above sea level and above the specified height; the power rating and other equipment specifications experience a reduction.

DDS02.1-A050-DS24-03-FW Documents

  • DDS021A050DS2403FW
  • DDS02 1 A050 DS24 03 FW
  • dds02.1-a050-ds24-03-fw

DDS02.1-A050-DS24-03-FW Technical Specifications

Cooling: External Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 50 A
