DDS03.2-W030-BE32-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911266424
The Bosch Rexroth Indramat DDS03.2-W030-BE32-01-FW is a digital AC servo drive controller in the DDS Drive Controllers series. It features a SERCOS communication interface and supports both digital servo and resolver feedback for motors. The drive has a rated current of 30 Amps and uses internal air cooling from within the control cabinet.
Internal Product Review
The DDS03.2-W030-BE32-01-FW is a digital AC servo drive controller rated for 30 A, making it a capable choice for demanding motion applications. SERCOS interface support and digital servo or resolver feedback provide precise integration and dependable control response. Internal cabinet air cooling adds practical installation value, making this controller a strong performer for servo systems.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS03.2-W030-BE32-01-FW belongs to the DDS Drive Controllers series produced by Bosch Rexroth Indramat. This modular servo drive controller is installed inside a control cabinet, where it regulates the current, velocity, and position of connected AC servo motors used in automated machining cells, handling gantries, and packaging lines. The device mounts beside compatible power supplies and communicates with higher-level motion systems to close the drive loop and coordinate axis behavior within the overall machine cycle. Its modular layout also lets it operate with matching supply and interface modules in the same cabinet.
The controller exchanges real-time commands over the SERCOS interface, giving deterministic timing for synchronized multi-axis profiles. Its power electronics deliver a continuous output of 30 A, allowing it to run medium-power servomotors at rated torque. Heat is removed by internal air cooling, so no external ducting is required and cabinet cleanliness is maintained. Feedback flexibility is provided through support for digital servo feedback and resolver feedback, allowing use with high-resolution encoders as well as rugged resolver transducers. Indramat classifies this model as a Digital AC Servo Drive Controller, so signal processing, parameter storage, and diagnostics are handled in the digital domain for repeatable operation.
The unit is part of Line 03, so its mechanical dimensions and backplane connectors match other modules in the same family. The assembly is built to Version 2, which identifies the revision used for this hardware. The unit uses function ID version 01 for its command structure, keeping control behavior consistent within compatible DDS systems. These identifiers help distinguish the controller’s hardware revision and command format within the product line.
