Product Description:

The DDS02.2-W200-BE78-00-FW is a drive controller developed by Bosch Rexroth Indramat and grouped within the DDS Drive Controllers series. Designed for cabinet installation, the unit forms the power and control interface between Indramat servo motors and higher-level automation hardware. By adjusting current and velocity loops in real time, the controller directs torque delivery to brushless motors used on packaging lines, printing presses, and assembly stations. Because the control and power stages are combined in one cabinet-mounted module, it suits centralized machine layouts where several axes are coordinated from a common enclosure.

Communication with the machine control layer occurs through the SERCOS interface, which carries cyclic position and status data over fiber optics and helps reduce electrical noise inside the cabinet. Thermal management relies on internal air cooling, so the enclosure must provide enough airflow to remove the heat generated by the power section. The power stage is rated for a continuous output of 200 A, allowing the drive to energize large synchronous motors during demanding motion cycles. For closed-loop position control, the controller accepts both digital servo feedback and resolver feedback, so it can work with either high-resolution encoder-equipped motors or analog resolver-based motors.

Project setup uses a plug-in firmware cartridge, and the required software is supplied as a separate subitem. This arrangement allows the controller to be matched to the intended operating functions without changing the base hardware. The unit is part of Line 02 and is built as Version 2, indicating a later revision of this controller platform. It is a Digital AC Servo Drive Controller that can operate with other DDS axes in coordinated multi-drive systems without additional fieldbus converters.
