DDS02.2-W200-BE34-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911265355
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
4 Minutes
6 Seconds
The Bosch Rexroth Indramat DDS02.2-W200-BE34-01-FW is a digital AC servo drive controller from the DDS Drive Controllers series. It supports SERCOS interface communication and provides a rated current of 200 Amps. This unit uses air cooling from inside the control cabinet and is equipped with digital servo and resolver feedback, with operational temperatures ranging from 0 to 45 degrees Celsius.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS02.2-W200-BE34-01-FW is an AC servo drive controller built by Bosch Rexroth Indramat for use in the DDS Drive Controllers series. As a digital drive unit, it regulates three-phase servo motors in automated machinery by converting commanded velocity and torque values into precise current output. The device serves as the axis interface between the machine control system and the connected motor, providing closed-loop regulation, diagnostics, and communication for coordinated motion in industrial automation lines. It is suited for applications that require accurate motor response during positioning, speed control, and repeatable production cycles.
The controller communicates with higher-level PLCs over the SERCOS interface, so timing data and operating parameters are exchanged on a deterministic optical ring. Thermal loading is removed by air from inside the control cabinet, which means the unit depends on cabinet airflow rather than an integrated blower. An IP20 protection rating permits installation in clean electrical enclosures where contact protection is needed but dust-tight sealing is not required. The power stage delivers a continuous output of 200 A, allowing it to operate medium-to-large synchronous motors without current derating in normal use. Ambient operating temperature must stay between 0 – 45 °C so the controller can maintain stable performance during regular machine operation.
Installation conditions also matter for reliable use. Altitudes up to 1000 m above sea level are permitted before cooling performance must be reevaluated. During storage or transport, the electronics can withstand temperatures from -30 – 85 °C without damage when the unit is not operating. The controller supports both digital servo feedback and resolver feedback, making it compatible with different motor feedback systems used across servo applications. This flexibility allows one drive platform to work with motors that prioritize high-resolution position data or robust feedback behavior in demanding operating environments.
Frequently Asked Questions about DDS02.2-W200-BE34-01-FW:
Q: What is the rated current output of the DDS02.2-W200-BE34-01-FW drive?
A: The DDS02.2-W200-BE34-01-FW can deliver a rated current of 200A to connected motors.
Q: Which communication interface is supported by the DDS02.2-W200-BE34-01-FW?
A: This model uses a SERCOS interface for communication, enabling fast and standardized digital data exchange.
Q: How is the DDS02.2-W200-BE34-01-FW cooled during operation?
A: The drive controller operates with internal air cooling using airflow from within the control cabinet.
Q: What motor feedback types are compatible with the DDS02.2-W200-BE34-01-FW controller?
A: This unit accepts both digital servo feedback and resolver feedback from motors, supporting flexible motor feedback options.
Q: What is the protection rating of the DDS02.2-W200-BE34-01-FW?
A: The protection category for this model is IP20, offering protection against solid objects greater than 12.5mm but no water resistance.
