DDS02.2-W200-BE11-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911267134
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
4 Minutes
4 Seconds
The Bosch Rexroth Indramat DDS02.2-W200-BE11-01-FW is a digital AC servo drive controller in the DDS Drive Controllers series. It features a SERCOS communication interface and supports both digital servo and resolver feedback. The controller has a rated current of 200 Amps, an IP20 protection category, and operates between 0 and 45°C with internal air cooling from within the control cabinet.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS02.2-W200-BE11-01-FW belongs to the DDS Drive Controllers series from Bosch Rexroth Indramat. It is a digital AC servo drive controller that regulates the power stage of synchronous and induction motors in automated machinery. By combining drive electronics with standardized communication and feedback channels, the unit links a higher-level motion system to the attached motor for coordinated axis control within an industrial automation cell. It also serves as the interface between a regulated DC bus and the motor windings, converting command values from the motion controller into controlled output current.
The drive communicates with the host control system through a SERCOS interface, giving deterministic cycle times for position, velocity, and diagnostic data. It supports a continuous phase current of 200 A, so it can be paired with high-torque motors without oversizing the supply section. Cooling uses air from inside the control cabinet, which requires unobstructed airflow around the heat sink. An enclosure rating of IP20 limits the device to protected indoor panels where contact with live parts is prevented by cabinet mounting. The permissible ambient operating range is 0 – 45 °C, which suits most machine rooms with conditioned air or forced ventilation.
Position feedback can be processed through digital servo feedback and resolver feedback, allowing mixed-technology installations on the same SERCOS ring. Installations up to 1000 m above sea level do not require output derating. During long-term storage or transport, the electronics remain stable between -30 – 85 °C. The hardware platform uses Version 2 logic and is assigned to Line 02 with Function ID 01. Because it accepts both feedback types, the controller can support encoder-based servo axes as well as resolver-equipped motor configurations within the same machine layout.
Frequently Asked Questions about DDS02.2-W200-BE11-01-FW:
Q: What types of motor feedback are supported by the DDS02.2-W200-BE11-01-FW?
A: This drive controller supports both digital servo feedback and resolver feedback for motor position and speed detection.
Q: What is the rated current of the DDS02.2-W200-BE11-01-FW drive controller?
A: The maximum rated current for this model is 200A, allowing high power output for demanding servo applications.
Q: What communication interface is used by the DDS02.2-W200-BE11-01-FW?
A: The SERCOS interface is used for communication, ensuring compatibility with industry-standard automation systems.
Q: What cooling method is used in the DDS02.2-W200-BE11-01-FW?
A: This drive controller utilizes internal air cooling from inside the control cabinet for temperature management.
Q: What is the maximum installation elevation for the DDS02.2-W200-BE11-01-FW?
A: The DDS02.2-W200-BE11-01-FW can be installed at elevations up to 1000 meters above sea level.
