Product Description:

The DDS02.2-W200-BE09-01-FW drive controller is built by Bosch Rexroth Indramat within the DDS Drive Controllers series. Classified as a digital AC servo drive controller, it supplies regulated three-phase power to matched synchronous or induction motors in automated machining cells, packaging lines, assembly conveyors, and material-handling stations. Through closed-loop current and velocity regulation, the unit coordinates precise motor motion in response to drive commands from higher-level PLCs and CNCs. It is suited for installations where coordinated motor control must remain consistent during repeated start, stop, and speed-change sequences. This operating role helps connected axes follow machine timing without unnecessary variation.

Electrical capacity is anchored by a continuous output of 200 A, allowing the controller to energize medium to large servo axes without current derating. Command data reach the device over a SERCOS interface, so fiber-optic rings can tie multiple axes together with deterministic update cycles and synchronized command transfer. Thermal management is handled by internal air cooling, meaning cabinet air is drawn past the heat sink rather than relying on an external blower or liquid exchanger. For position feedback, the drive processes digital servo feedback, enabling high-resolution encoder signals to be handled directly by the control loop. This combination supports stable power delivery while keeping command and feedback channels coordinated with the motor response.

The controller also accepts resolver feedback, which supports applications that use rugged analog position sensing. It is part of Line 02 and is released as Version 2 within the product range. Its motion functions use Function ID version 01, which corresponds to the control feature set assigned to this unit. Application software is supplied through a separate firmware order rather than being embedded in the hardware. This arrangement allows the hardware platform to be matched with the software package required for the intended axis task.
