Product Description:

The DDS02.2-W200-BA03-01-FW is a drive controller produced by Bosch Rexroth Indramat for the DDS Drive Controllers series. It is a digital AC servo drive component that supplies regulated power to matched Indramat motors in automated machining centers, pick-and-place stations, and material-handling cells. By interpreting velocity or torque commands from a higher-level motion processor, the unit modulates output current so that axes accelerate, decelerate, and hold position according to programmed profiles.

The controller can deliver a continuous output of 200 A, which is the maximum motor phase current the power stage can sustain under nominal cooling. Command data enters through an analog interface, allowing voltage or current reference signals from external PLC hardware. Thermal energy is removed by internal air cooling, so cabinet air moves across the heat sink without separate ducting. The housing has an IP20 rating, which helps prevent finger contact with live parts but still requires installation inside a closed electrical enclosure. The controller operates in ambient temperatures from 0 to 45 °C, helping maintain stable thermal conditions during normal use.

Installation height is limited to 1000 m above sea level, because thinner air at higher elevations reduces convective cooling. Feedback compatibility includes incremental encoders as well as digital servo feedback devices, allowing the drive to receive the closed-loop position or speed data needed for precise control. When the equipment is powered down, the unit can be stored between -30 to 85 °C without affecting capacitor life or insulation integrity. The parameter structure and I/O mapping correspond to Function ID version 01, and the unit is part of line 02 with version 2. This combination helps keep the control format aligned with the intended release of the product.
