DDS02.2-W100-BE52-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911273821
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
52 Seconds
The Bosch Rexroth Indramat DDS02.2-W100-BE52-01-FW is a Digital AC Servo Drive Controller in the DDS Drive Controllers series. It has a rated current of 100 Amps and uses air cooling from inside the control cabinet. The controller supports SERCOS communication interface and offers digital servo and resolver feedback for motors.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS02.2-W100-BE52-01-FW is a digital AC servo drive controller produced by Bosch Rexroth Indramat within the DDS Drive Controllers series. It interprets motion commands and modulates phase currents so connected servo motors track speed, torque, and position references in automated machinery. Installed beside matching supply modules on a common rail, it forms the axis-level link between a higher-level PLC and electromechanical drive hardware. This arrangement supports real-time closed-loop control for production lines, transfer systems, and other coordinated motion applications where repeatable axis behavior is required.
The unit can deliver up to 100 A of continuous output current, so cabinet conductors and protection devices must be selected for that load. An IP20 housing limits exposure to dust and accidental contact, which means the controller is intended for installation inside an electrical enclosure rather than in open machine areas. Communication with the control system occurs over a SERCOS interface, providing deterministic fiber-optic data exchange for synchronized multi-axis motion. Heat removal relies on internal air cooling that draws cabinet air across the heat sink, so unrestricted airflow inside the enclosure is important during operation. The controller operates reliably in ambient conditions from 0 to 45 °C, and higher temperatures can reduce thermal margin during sustained axis loading.
For storage or transport, it withstands environments between -30 to 85 °C, which supports normal warehouse handling before installation. The maximum installation altitude is 1000 m; locations above that height may require derating because lower air density reduces cooling effectiveness. Feedback options include digital servo feedback or resolver signals, allowing compatibility with a broad range of motor feedback systems used in servo applications. The controller uses Function ID version 01, and the unit is part of Line 02 and Version 2 so startup and communication settings remain matched to the drive configuration.
Frequently Asked Questions about DDS02.2-W100-BE52-01-FW:
Q: Which communication interface is used by the DDS02.2-W100-BE52-01-FW drive controller?
A: This model communicates using the SERCOS interface for real-time control signals.
Q: What types of motor feedback are supported by the DDS02.2-W100-BE52-01-FW?
A: The DDS02.2-W100-BE52-01-FW supports both digital servo feedback and resolver feedback for motor control.
Q: How is the DDS02.2-W100-BE52-01-FW drive controller cooled?
A: Cooling is achieved by air circulation from inside the control cabinet, utilizing internal airflow.
Q: What is the rated current specification for this drive controller?
A: The DDS02.2-W100-BE52-01-FW has a rated current of 100A for its operation.
Q: What is the protection rating of the DDS02.2-W100-BE52-01-FW?
A: It has a protection category of IP20, offering limited protection against solid objects larger than 12.5 mm but no protection against liquids.
