Product Description:

The DDS02.2-W100-BA01-01-FW belongs to the DDS Drive Controllers series produced by Bosch Rexroth Indramat. It is a modular servo drive unit used to regulate the torque, velocity, and position of AC servo motors in automated machinery. By converting command signals from higher-level motion controllers into controlled three-phase output, the drive closes the electrical loop between the machine PLC and the motor. This allows precise execution of programmed motion sequences on assembly lines, packaging systems, and handling axes.

This model communicates with the machine control system through an analog interface, so velocity or torque references are provided as continuous voltage or current signals rather than network messages. The drive can deliver up to 100 A of continuous output current, enabling it to operate medium-frame motors that draw high current during acceleration. Thermal management is handled by internal cabinet air cooling, and the integrated fan moves cabinet air across the heat sink without external ducting. Position and speed are returned through digital servo feedback or resolver feedback, letting the same unit operate motors equipped with either feedback system. The unit is part of Line 02, which matches the second-generation DDS platform.

The drive is Version 2, which provides expanded diagnostic capability compared with earlier releases. This version supports more detailed fault reporting for overcurrent, feedback, and temperature conditions during operation. Motion functions are selected by Function ID 01, keeping the parameter structure consistent for machines that use this drive type. Its modular format supports use with companion supply modules and option cards in the DDS platform. The controller continues to regulate torque, speed, and position directly from analog reference signals while monitoring system status during operation.
