DDS02.2-W050-BE41-01-FW
MPN: R911273290
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 3-5 Days
The DDS02.2-W050-BE41-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 50 A rated current, and Digital Servo and Resolver Feedback.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS02.2-W050-BE41-01-FW drive controller comes with a rated current of 50A. This Bosch Rexroth controller has an IP 20 degree of protection in compliance with EN 60529 / DIN VDE 0470-1 specifications. The product supports connectivity to a motor that renders digital and resolver feedback through its encoder. The device has two analog diagnostic outputs that generate drive internal variables for test purposes. These outputs have an output voltage of 10V and a current load capacity of 4mA. The unit is also equipped with two control inputs for its relay coils. It implements a starting lockout mechanism that prevents the connected motor from starting up unintentionally when there is a fault.
The drive controller houses an RS 232 serial interface for connection with a PC or a VT-100 terminal. The product connection to the motor feedback is done through its X4 connecting point. The device utilizes an E-DDS2 electrical connecting accessories kit to simplify its connection process. This kit includes two DC bus rails for the power connection, an 11-pin plug-in terminal that serves as a connector for I/Os and a 6-pin plug-in terminal functioning as a connector for the motor brake and the external 24VDC supply voltage. This controller comes with a warranty tag for one year.
The product features a function ID code of 41 as determined and fixed by the manufacturer. The device depicts a maximum permissible relative humidity of 95%. The configuration plate of the unit features the term COVER if a particular slot does not have any plug-in module. Its U5 slot is solely reserved for inserting the software module. The drive controller requires minimum mounting and installation effort. The software module required by the product depends on its functions. This module encompasses the parameters of both the drive and firmware. This DDS02.2-W050-BE41-01-FW controller is shipped through reputed freight carriers with a wide network.
