Product Description:

The DDS02.2-W015-BE24-02-FW is a digital AC servo drive controller produced by Bosch Rexroth Indramat for the DDS Drive Controllers series. Installed in multi-axis automation racks, this controller regulates torque, speed, and position of matched servo motors in industrial processing lines. By translating motion commands from upper-level controls into precisely modulated output, it forms the core of many packaging, material-handling, and machine-tool systems. Its digital control structure supports repeatable axis response during frequent starts, stops, and position changes.

Its communication backbone is the SERCOS interface, allowing deterministic real-time exchange with PLCs over fiber optics. During operation, the unit supplies a continuous 15 A output to the motor windings, a current level suited to small and medium servo axes. Thermal management is handled through internal air cooling, meaning cabinet airflow removes generated heat without external heat sinks. Component protection against accidental contact and settled dust is provided by IP20, so the controller is intended for closed electrical enclosures. Reliable function is maintained across an ambient range of 0 – 45 °C, which suits typical industrial cabinet conditions. This enclosure style is intended for protected installation inside the machine cabinet rather than direct exposure on the machine frame.

Installation can occur at elevations up to 1000 m above sea level without changing normal electrical operation. The control loop accepts both digital servo feedback and resolver feedback, allowing compatibility with both legacy motor systems and higher-resolution feedback devices. This flexibility is useful when a machine platform includes different motor types across separate axes. Long-term storage is permitted between −30 – 85 °C, so the controller can be stored in typical indoor industrial spaces without added climate control. The controller belongs to line 02 and carries version 2 electronics.
